Replacing Gateway Notebook Components www.gateway.com
32
18 Gently press the keyboard down until it is flat all the way across. The
keyboard should easily fall into place. Be careful not to damage the
LCD panel.
19 Reinstall the keyboard cover by following the instructions in “Replacing
the keyboard cover” on page 26.
20 Turn the notebook over so the bottom is facing up.
21 Replace the screws removed in Step 8.
22 Replace the wireless cover, then tighten the screw.
23 Replace the memory bay cover, then tighten the six screws.
Tips & Tricks
The screw hole is marked with a K.
24 Replace the keyboard screw.
25 Reassemble the notebook.
