Replacing the LCD panel inverter
www.gateway.com
41
6 Remove the two screws holding the bracket to the LCD panel assembly,
then remove the bracket.
7 Unplug both cables from the inverter.
8 Remove the old inverter, then insert the new one.
9 Connect the cables to the new inverter.
10 Replace the bracket, then replace the two screws removed in Step 6.
11 Reassemble the notebook.
ScrewScrew
