Replacing Gateway Notebook Components www.gateway.com
50
10 Turn the notebook over so the bottom is facing up. Remove the 17 screws
shown in the following picture. Note the location of the six short screws.
11 Lift the palm rest assembly completely from the notebook.
12 Place the new palm rest assembly onto the notebook, then snap the
assembly into place.
13 Replace all of the palm rest screws.
14 Reassemble the notebook.
Screws
Screws
