GATEXPERT SW200DC - Cable List

Instructions for SW200DC
www.gatexpertstore.com
5
6. Cable List
Cable Application
Cable Material
Max. Length
1
Cable of 220V control box’s power
supply
3×2.5mm² (
＞
30m)
3×1.5mm² (
＜
30m)
Unlimited
2
Cable of gate opener’s power supply
2×1.5mm²
15m
3
Cable of infrared sensor
2×0.5mm²
10m
4
Cable of alarm lamp
2×0.5mm²
10m
5
Cable of electric lock
2×0.5mm²
10m
6
Extension cable of storage battery
2×1.5mm²
10m
7
Cable of solar power
2×1.5mm²
10m
Due to different installation environments, installer need to prepare power cables for
control box and for gate openers.
Note: cable outlet should be downward to prevent rainwater from entering
wire along the cable.
