GATEXPERT SW200DC - Direction of Gate Opening; Gate Opens Inwards

Instructions for SW200DC
www.gatexpertstore.com
6
7. Direction of Gate Opening
7.1 Gate Opens Inwards
开门方向
开门位置安全挡块
限位挡块
Figure 2
Recommended Installation Size:
Note: If the interval between the gate and the wall is too small or it has
interference after the gate completely open, please install a gate safety
stopper(prepare by user) to prevent injury to person or
damage to property.
A
B
100mm
120 mm
140 mm
160 mm
180 mm
200 mm
100mm
103°
111.5°
118.5°
120.5°
108°
100.5°
120mm
101°
108.5°
115°
110°
100.5°
94.5°
140mm
99.5°
106.5°
112.5°
101°
94°
160mm
98.5°
104.5°
101.5°
93°
180mm
97.5°
103°
92°
200mm
97°
90.5°
Limit
stopper
Gate opening
direction
Safety
stopper
