7.1.2 Diagnostic LED – Bill Reject Codes
If a bill is rejected then a flash code is given when the bill is removed (the LED will
flash red or orange a number of times):
Cause of Bill Rejection Number of flashes
Unrecognised bill 1 Red
Optical Anti String Gate was triggered 2 Red
Bill Inhibited in the configuration or by DIP switch 3 Red
Bill Inhibited by the Host 3 Orange
Bill slipped or was held by the user as it was scanned 4 Red
Bill inserted skewed 5 Red
Bill is too long or two bills inserted 6 Red
7.1.3 Illuminated Bill Guide Patterns
The illuminated bill guide can be configured to flash different patterns according to
the validator state. The standard patterns are:
ST1C State Pattern
Out of Service - fault Bill Guide off
Not accepting bills at the request of the host
controller
Flashes momentarily every
2.5 seconds
In service, waiting for a bill Bill Guide on
In service, handling a bill Flashes continuously
