Testing

DO complete the cable installation testing BEFORE final termination at either end

DO record the cable loop resistance values to aid troubleshooting later

Documentation

DO record cable routing and equipment/junction box locations

DO track all changes by updating the system documentation

DO keep records adjacent to the equipment
