GDS Combi - Fig. 4 Circuit Board Identification

40
Fig. 3 Combi Controller Network Configuration
CAN 2 CAN 2
Sensors
CAN 1
4 core
Combi Network Controller
Scans/controls up to x16
combi panels
CAN 2
Sensor line
Sensors
CAN 1
Sensors
CAN 1
Sensors CAN 1
Sensors
CAN 1
Sensors
CAN 1
Sensors
CAN 1
Sensors
CAN 1
1~16 direct
1~64 Addressable
CAN 2
CAN relay unit - 4 relays
Relay unit 2 x 32 relays
CAN 2
