The LEDs local to the panel are as follows:
Alarm Internal/ Colour Description
External
Or Alarm I Red on if any sensor currently has an over range alarm
Lo Alarm I Red on if any sensor currently has a low alarm
Hi Alarm I Red on if any sensor currently has a high alarm
DC fail I Amber on if battery is low
AC fail I Amber on if mains has failed
Sensor fail I Amber on if any sensor has failed
CAN fail I Amber on if any addressable sensor has stopped communicating
Modbus fail I Amber on if the Modbus master has stopped communicating
System Inhibit I Amber on if the system is not checking alarms
Sensor Inhibit X Amber on if any sensor has been inhibited
Watchdog I Amber on if the processor has had a watchdog reset
Power I Green on if power applied
Fault X on if a fault exists
Alarm X on if alarm exists
(I = view internal X = view external)
If the fault or alarm LED is flashing, this indicates a new event and when accepted by
pressing the UP (1) button it remains on (not flashing).
