Operation
Panel operation in standby
Normal operation (standby) is indicated as shown below.
Table 8: Normal operation
LED indicator Status
Supply ON The green LED is steady
Processor running The green LED is flashing
Sounder indicators: Delay ON or
Delay OFF
The yellow Delay ON LED is steady when a delay is running. This is
logged as a condition. Press the SILENCE BUZZER button to silence
the internal buzzer.
Fire brigade indicators: Delay ON
or Delay OFF
The yellow Delay ON LED is steady when a delay is running. This is
logged as a condition. Press the SILENCE BUZZER button to silence
the internal buzzer.
All other LEDs OFF
Figure 8: System Status menu (normal operation)
X Î
SYSTEM STATUS Fri 12/10/04 09:17:37
(Site text – up to 40 characters)
Y Î
(Site text – up to 40 characters)
Z Î
Scanning Day Mode Zones on E
[ Î
\ Î
Alarm: 0 Faults: 0 Cond.: 0 P: 1 SDZ
1. Menu title, date, and time
2. Site text (up to 40 characters)
3. Operations status line (operations are displayed in full here)
4. User keys (none shown in this screen)
5. System status. The current number of fire alarms, faults, and conditions are
displayed here as well as repeater information (P is global with panel number
shown, L is local) and a summary of the operations (eg, SDZ).
