GE 12R II Series User Manual

COE Communications Engineering Document
Author:
Keith Gilbertson
Rev:
A
Date:
3/08/02
Pag
e:
22
of 33
GE
TRANSPORTATION
SYSTEMS
GLOBAL SIGNALING DIVISION
Title:
12RII FCC TECHNICAL MANUAL
8.7. Power Supply Board Parts List
227409-001 ASSY 36V POWER SUPPLY BRD X
227409-000 ASSY 74V POWER SUPPLY BRD X
GSPN DESCRIPTION QTY QTY REF DES / DIN
001011-002 CAP ALUM 35V 220UF RAD LS 5 1 C21
001011-205 CAP ALUM 200V 10UF 0.2RAD L/S 2 C8-9
001011-110 CAP ALUM 100V 33UF 0.2RAD L/S 2 C8-9
001026-021 CAP CER 500V .01UF 20%Z5U DISC 2 2 C6-7
001129-2024 CAP CER DISK 3000V .01UF 20% 4 4 C1-2 C18-19
001152-081 CAP TANT SOL 20V 10UF 10% AX 2 2 C24-25
001152-087 CAP TANT 25V 1UF 10% AXIAL 1 1 C12
001152-227 CAP TANT SOL 25V 47UF 10% AU 2 2 C13-14
001258-024 CAP CER SPIN 100V 1000PF 10% 3 3 C10 C17 C20
001258-062 CAP CER SPIN 50V .1uf 10% X7R 7 7 C11 C16 C22-
23 C26-28
001284-100 CAP PYEST 250V .47UF 5% .59RAD 1 1 C3
001387-101 CAP ALUM 200V 1500UF SNP 35X40 2 C4-5
001387-102 CAP ALUM 100V 3300UF SNP 35X40 2 C4-5
002129-7109 RES CF 1/2W 1 OHM 5% 2 2 R1-2
003227-000 IC LM340T VOLTAGE REGULATOR 5V 1 1 U3
003227-002 IC LM340T COM 8VREG TO220 1 1 U2
010001-028 FUSE 3AG 250V 4A SLO BLO GLA 1 F1
010001-035 FUSE 3AG 250V 6.25A SLO BLO GLA 1 F1
010021-001 MOV 14VRMS 1000A 4J .3" RAD 1 1 RV2
010042-006 MOV 130VRMS 6500A 70J .3" RAD 1 1 RV1
010101-005 FUSE FAST BLO 15A AUTOMOTIVE 1 1 F2
011013-043 DIODE 1N6288A 1.5KE51A TS PL 2 D3-4
011013-029 DIODE 1N6281A 1.5KE27A TS PL 2 D3-4
011144-001 DIODE MR756 RECT 600V 6A 2 2 D1-2
016244-000 IND 140UH 40AMP 1 1 L3
016258-000 IND 15uH 1 1 L4
016246-013 INDUCT CM CHOKE 2MH 7.5A 4RAD 1 1 T2
016263-003 INDUCTOR 285UH 2 L1-2
016263-010 INDUCTOR 100UH 2 L1-2
029749-000 RTV 0.02 0.02 6
032507-000 TERMINAL .250 TAB 6 6 J1-6
032022-008 CONN 8CKT 2MM HEADER 1 1 J7
032003-000 SOCKET VICOR MAXI SMT 4-PIN OUTPUT 1 1 2
032003-001 SOCKET VICOR MAXI SMT 5-PIN INPUT 1 1 3
032866-003 FUSEHOLDER PC VERT MT H 1 1 5
132222-000 SCKT FUSE CLIP AUTO 15A 2 2 4
062311-000 PCB 12RII POWER SUPPLY 1 1 1
135630-000 SCHEM 12RII POWER SUPPLY REF REF
