GE 12R II Series User Manual

COE Communications Engineering Document
Author:
Keith Gilbertson
Rev:
A
Date:
3/08/02
Pag
e:
31
of 33
GE
TRANSPORTATION
SYSTEMS
GLOBAL SIGNALING DIVISION
Title:
12RII FCC TECHNICAL MANUAL
12.1. Front Panel Parts List
227410-000 ASSY 12RII FRONT PANEL
GSPN DESCRIPTION QTY REF DES / DIN
227410-100 ASSY 12RII FRONT PANEL BOARD 1 1
202926-000 ASSY 12RII PROCESSOR MODULE 1 2
022207-100 Keypad Left 1 6
022207-200 Keypad Numeric 1 7
022207-300 Keypad Right 1 8
006128-000 Foam 12R Speaker insert 1 15
006128-001 Foam 12R Mic insert 1 16
123363-001 GRILLE 12R SPEAKER 3.35 1 14
202298-100 PANEL 12RII FRONT W/LENS 1 5
013492-3810 SCREW 10-24X5/16 PPH SS 4 12
013496-3410 SCREW 4-40 X 5/16 PPH I 12 10
227173-001 ASSY SPEAKER 4 OHM 1 4
202167-001 ASSY LCD 12RII 2x16 1 3
