GE 12R II Series User Manual

COE Communications Engineering Document
Author:
Keith Gilbertson
Rev:
A
Date:
3/08/02
Pag
e:
32
of 33
GE
TRANSPORTATION
SYSTEMS
GLOBAL SIGNALING DIVISION
Title:
12RII FCC TECHNICAL MANUAL
12.2. Front Panel Board Parts List
227410-100 ASSY 12RII FRONT PANEL BOARD
GSPN DESCRIPTION QTY REF DES / DIN
001358-101 CAP CER CHIP 50V 100pF 0805 5 C17-18 C41 C44-45
001360-102 CAP CER CHIP 50V 1000pF 10% 0805 8 C3-8 C10-11
001360-104 CAP CER CHIP 50V .1UF 10% 0805 20 C2 C9 C12-13 C15-16 C19-22 C25
C27-30 C35 C37-40
001377-229 CAP TANT CHIP 1.0uF 20% 16V TANT3216 3 C14 C26 C32
001377-232 CAP TANT CHIP 4.7uF 20% 16V TANT3528 4 C23-24 C36 C42
001377-252 CAP TANT CHIP 10uF 20% 25V 7343 2 C1 C31
002266-5681 RES CHP 1/10 680 OHM 5% 0805 2 R41-42
002266-5823 RES CHP 1/8W 82K 5% 805 5 R37 R47 R86-88
002278-1002 RES 10.0K OHM 1/10 W 1% 0805 16 R22 R25 R29 R35 R39 R43 R72 R75-79
R81 R84 R89-90
002278-1009 RES 10.0 OHM 1/10 W 1% 0805 2 R32-33
002278-1210 RES 121 OHM 1/10 W 1% 0805 5 R34 R36 R49-50 R82
002278-1241 RES 1.24K OHM 1/10 W 1% 0805 48 R1-21 R26 R30 R45 R48 R51-70 R73-
74 R80
002278-2430 RES 243 OHM 1/10 W 1% 0805 4 R23 R27-28 R71
002278-4022 RES 40.2K OHM 1/10 W 1% 0805 7 R24 R31 R38 R44 R46 R83 R85
002278-4750 RES 475 OHM 1/10 W 1% 0805 1 R40
003377-010 IC MC33072 IND DUAL OPAMP SOIC8P 1 U6
003444-075 IC LM75 A/D TEMP SENSOR MSOP8 1 U9
003574-004 IC 8KX8 I2C SER EEPR SO8 1 U8
003732-002 IC +5V REG LM10861 1 U2
003738-005 IC LT1785IND RS485 XCVR60V 1 U5
003758-029 IC MX029TN IND DIG TSSOP24 1 U7
003759-000 IC MAX 202 +5V RS-232 TRANSCEIVER 1 U4
004204-000 XSTR MMBT3904 NPN SOT-23 2 Q1 Q3
004253-003 XSTR NDT3055LOGIC NFET3.5A S 1 Q2
009330-000 SWITCH SPST MOM W/LED SMT 29 S1-29
011040-002 DIODE MMBD7000LT1 DUAL SWITCHING SOT- 7 D1-7
011233-000 LED ORN CHP 50MW 0805SMT 50M 4 DS1-4
018132-001 MIC EM100T PC MOUNT 1 MK1
018132-102 MIC 100E RUBBER BOOT 1 2
032022-203 CONN HDR 1X3 PIN MAL 2mm SMT 1 J6
032022-210 CONN HDR 1X10 PIN MAL 2mm SMT 1 J4
032022-212 CONN HDR 1X12 PIN MAL 2mm SMT 1 J3
032290-9009 SCKT SNGL .019DIA TIN CLOSED 2 J7-8
132360-220 CONN SCKT 2x20 2mm SMT 2 J1-2
132360-216 CONN SOCKET 32P SMT BOTTOM ENTRY 1 J5
062312-000 PCB 12RII FRONT PANEL BRD 1 1
135631-000 SCHEM 12RII FRONT PANEL BRD ref
