10 GE Contactless Smart Card Reader Model 24x
Wiring
Table 2: Reader 12-Position Field Wiring Connector
Pin Definition
1 Micro control, reader beeper (option)
2 Ground
3 8VDCto30VDC
4 Door contact
5 Reader Data 1
6 Exit request (REX)
7GreenLED
8 Micro control, red LED (option)
9 RS-485-B, reader firmware maintenance
10 RS-485-A, reader firmware maintenance
11 Reserved for future use
12 Reserved for future use
