GE Contactless Smart Card Reader Model 24x 15
Table 4: 2RP Reader Board Address Settings
Note: Switches SW2-5, 6, 7, and 8 are not used.
Jumper W1 RN2 and RN5 (labeling)
Set to 12 V Use 2k Ω (202) resistor packs.
Table 3: 2RP Reader Switch Settings
Reader Technology
and Format
SW-1 SW-2 SW-3 SW-4
Supervised F/2F ON OFF ON OFF
Reader
Board
SW 1 SW 2
5 6 7 8 1 2 3 4
1
ON OFF OFF OFF ON OFF OFF OFF
2
OFF ON OFF OFF OFF ON OFF OFF
3
OFF OFF ON OFF OFF OFF ON OFF
4
OFF OFF OFF ON OFF OFF OFF ON
