GE Contactless Smart Card Reader Model 24x 17
Note: the 8RP board appears to the Micro as four 2RP boards.
Table 5: 8RP Reader Technology and Format
Reader Technology and
Format
SW1-1 SW1-2 SW1-3 SW1-4
Supervised F/2F ON OFF ON OFF
Table 6: 8RP Board Address Settings
Board Type
SW 1
5 6 7 8
Standard ON ON ON OFF
Board 1
a
a. Readers 1 - 8
Does not apply. OFF ON
Board 2
b
b. Readers 9 - 16
OFF ON
Board Type
SW 2
1 2 3 4 5 6 7 8
Standard
OFF OFF ON ON ON OFF ON OFF
Board 1
a
a. Readers 1 - 8.
ON OFF ON OFF ON OFF ON OFF
Board 2
b
b. Readers 9 -16.
ON ON OFF OFF OFF ON OFF ON
