CONNECT PROBE AND TRANSFORMER
TO CONTROLLER
WARNING
Do Not allow this controller to come in contact
with Liquid Nitrogen vapors
MODEL 610
Model 610 5
Plug the 9 Volt AC Transformer into proper AC outlet. It is imperative, for safe and stable
operation, that the controller be connected to a properly grounded AC outlet. Unfortunately,
some of the three (3) prong outlets are not properly grounded. Check to make sure that the
outlet to be used is connected to a known ground BEFORE plugging in the AC power cord.
Proper AC Outlet
9 Volt
Transformer
9 Volts AC
Low Sensor Probe
9 Volt
Transmittor
Connector (B)
Plug the Probe (A) into the Controller (as shown above).
Plug the 9 Volt AC Transformer connector (B) into the Controller (as shown above).
The Power LED will light.
(B)
(A)
Horn
To Next Page
