Autonomy times for lead acid batteries (VRLA)
192 cells Autonomy at full load at PF=0.8 U floating = 436 Vdc (2.27 Vdc - cell)
Battery with expected trickle life 5 years Battery with expected trickle life 10 years
UPS model 10Ah 17Ah
24/26
Ah
33Ah 38Ah 65Ah
2x38
Ah
75Ah 100Ah
150Ah
200Ah 300Ah 400Ah
500Ah
SitePro 10 kVA 9 16 30/31 45 52 105 - 135 - - - - - -
SitePro 15 kVA - 11 15/16 26 32 62 - 84 117 - - - - -
SitePro 20 kVA - 6 10/11 18 22 42 - 58 84 135 - - - -
SitePro 30 kVA - - 5/6 11 12 27 - 36 50 84 117 - - -
SitePro 40 kVA - - - 6 7 18 - 24 6 58 84 135 - -
Stop Operation time
Residual battery autonomy time before UPS forced shutdown.
Standard set 3 minutes.
Settable from 1 minute to autonomy time in minutes (see tables).
Capacity
Ah capacity of the battery.
Cells
Number of cells of the battery.
Lead-Acid (VRLA): 177 ÷ 192 cells
NiCd: 281 cells
Boost: 182 ÷ 195 cells
Example:
180 battery cells
30 blocks / 12 Vdc battery 60 blocks / 6 Vdc battery 180 blocks / 2 Vdc battery
NOTE !
The values indicated above, must be considered as standard values.
The actual programmed values must be the ones defined from the battery manufacturer.
`Configuration
CONFIGURATION
Save and exit ?
Yes
CONFIGURATION screen
Screen to save the configuration of set parameters.
Any additional modification of setup parameters can be done
only from a GE SERVICE PERSON as it requires an access code.
Continue
►
