GE 8 Series User Manual

Modifications reserved Page 74/99
OPM_SPE_XXX_10K_40K_8GB_V020.doc Operating Manual SitePro 10-15-20-30-40 kVA / S8
`Configuration
BATTERY CONFIGURATION
Type : Lead Acid
Float voltage : 409 V
Recharge current : 003.3 A
Autonomy time : 006 min
Stop Operation time : 003 min
Capacity : 0033 Ah Cells : 180
ESC

BATTERY CONFIGURATION screen
Type
Battery type (Lead Acid / NiCd / Boost).
Lead - Acid Sealed Battery (VRLA).
NiCd Nickel Cadmium battery.
Boost O pen Batteries, which require sporadic refill
with distilled water.
Float voltage
Voltage to maintain battery charging.
Float voltage = Number of battery cells x battery float voltage per cell.
Typical battery float voltage per cell (ask the battery manufacturer for confirmation):
Lead-Acid (VRLA): 2.27 Vdc for cell 180 cells x 2.27 Vdc = 409 Vdc
NiCd: 1.41 Vdc for cell 281 cells x 1.41 Vdc = 396 Vdc
Boost: 2.23 Vdc for cell 180 cells x 2.23 Vdc = 401 Vdc
Recharge current
Maximum battery recharge current.
Max 20% of battery capacity (Ah).
Example: 100Ah - max recharging current 20A.
Autonomy time
The autonomy time of the battery.
UPS autonomy on battery mode at full load condition.
This value is calculated based on the battery type, capacity and number of cells.
Autonomy times for lead acid batteries (VRLA)
180 cells Autonomy at full load at PF=0.8 U floating = 409 Vdc (2.27 Vdc - cell)
Battery with expected trickle life 5 years Battery with expected trickle life 10 years
UPS model 10Ah 17Ah
24/26
Ah
33Ah 38Ah 65Ah
2x38
Ah
75Ah 100Ah
150Ah
200Ah 300Ah 400Ah
500Ah
SitePro 10 kVA 8* 15* 28/30* 43* 50* 100* 120* 120 - - - - - -
SitePro 15 kVA - 10* 13/15* 24* 30* 60* 70* 74 103 - - - - -
SitePro 20 kVA - 6* 9/10* 16* 20* 40* 50* 51 74 120 - - - -
SitePro 30 kVA - - 5/6* 10* 12* 25* 30* 32 45 74 103 - - -
SitePro 40 kVA - - 6* 7* 17* 20* 21 32 51 74 120 - -
*) Autonomy time for battery supplied by GE UPS manufacturer.
Autonomy times for lead acid batteries (VRLA)
186 cells Autonomy at full load at PF=0.8 U floating = 423 Vdc (2.27 Vdc - cell)
Battery with expected trickle life 5 years Battery with expected trickle life 10 years
UPS model 10Ah 17Ah
24/26
Ah
33Ah 38Ah 65Ah
2x38
Ah
75Ah 100Ah
150Ah
200Ah 300Ah 400Ah
500Ah
SitePro 10 kVA 8 15 29/30 44 51 102 - 127 - - - - - -
SitePro 15 kVA - 10 13/15 25 31 61 - 79 110 - - - - -
SitePro 20 kVA - 6 9/10 17 21 41 - 54 80 127 - - - -
SitePro 30 kVA - - 5/6 10 12 26 - 34 47 80 110 - - -
SitePro 40 kVA - - - -6 7 17 - 22 34 55 80 127 - -
