11-142 869 MOTOR PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 11: MODBUS MEMORY MAP
81733 0xA304 EQL 9 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81735 0xA306 LO 9 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81737 0xA308 Events 0 1 1 FC126 1 1
Digital Counter 10
81738 0xA309 Function 0 1 1 FC126 0 1
81739 0xA30A Name 0 65535 1 F60_26 Counter 10 26
81752 0xA317 Units 0 65535 1 F60_6 units 6
81755 0xA31A Pre-set -2147483648 2147483647 1 F30 0 1
81757 0xA31C Compare -2147483648 2147483647 1 F30 0 1
81759 0xA31E Up 0 0xFFFFFFFF 1 FC142 0 1
81761 0xA320 Down 0 0xFFFFFFFF 1 FC142 0 1
81763 0xA322 Set to Pre-set 0 0xFFFFFFFF 1 FC142 0 1
81765 0xA324 Reset 0 0xFFFFFFFF 1 FC142 0 1
81767 0xA326 Freeze/Reset 0 0xFFFFFFFF 1 FC142 0 1
81769 0xA328 Freeze/Count 0 0xFFFFFFFF 1 FC142 0 1
81771 0xA32A Block 0 0xFFFFFFFF 1 FC142 0 1
81773 0xA32C HI 10 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81775 0xA32E EQL 10 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81777 0xA330 LO 10 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81779 0xA332 Events 0 1 1 FC126 1 1
Digital Counter 11
81780 0xA333 Function 0 1 1 FC126 0 1
81781 0xA334 Name 0 65535 1 F60_26 Counter 11 26
81794 0xA341 Units 0 65535 1 F60_6 units 6
81797 0xA344 Pre-set -2147483648 2147483647 1 F30 0 1
81799 0xA346 Compare -2147483648 2147483647 1 F30 0 1
81801 0xA348 Up 0 0xFFFFFFFF 1 FC142 0 1
81803 0xA34A Down 0 0xFFFFFFFF 1 FC142 0 1
81805 0xA34C Set to Pre-set 0 0xFFFFFFFF 1 FC142 0 1
81807 0xA34E Reset 0 0xFFFFFFFF 1 FC142 0 1
81809 0xA350 Freeze/Reset 0 0xFFFFFFFF 1 FC142 0 1
81811 0xA352 Freeze/Count 0 0xFFFFFFFF 1 FC142 0 1
81813 0xA354 Block 0 0xFFFFFFFF 1 FC142 0 1
81815 0xA356 HI 11 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81817 0xA358 EQL 11 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81819 0xA35A LO 11 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81821 0xA35C Events 0 1 1 FC126 1 1
Digital Counter 12
81822 0xA35D Function 0 1 1 FC126 0 1
81823 0xA35E Name 0 65535 1 F60_26 Counter 12 26
81836 0xA36B Units 0 65535 1 F60_6 units 6
81839 0xA36E Pre-set -2147483648 2147483647 1 F30 0 1
81841 0xA370 Compare -2147483648 2147483647 1 F30 0 1
81843 0xA372 Up 0 0xFFFFFFFF 1 FC142 0 1
81845 0xA374 Down 0 0xFFFFFFFF 1 FC142 0 1
81847 0xA376 Set to Pre-set 0 0xFFFFFFFF 1 FC142 0 1
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
