CHAPTER 11: MODBUS MEMORY MAP MODBUS MEMORY MAP
869 MOTOR PROTECTION SYSTEM – COMMUNICATIONS GUIDE 11-143
81849 0xA378 Reset 0 0xFFFFFFFF 1 FC142 0 1
81851 0xA37A Freeze/Reset 0 0xFFFFFFFF 1 FC142 0 1
81853 0xA37C Freeze/Count 0 0xFFFFFFFF 1 FC142 0 1
81855 0xA37E Block 0 0xFFFFFFFF 1 FC142 0 1
81857 0xA380 HI 12 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81859 0xA382 EQL 12 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81861 0xA384 LO 12 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81863 0xA386 Events 0 1 1 FC126 1 1
Digital Counter 13
81864 0xA387 Function 0 1 1 FC126 0 1
81865 0xA388 Name 0 65535 1 F60_26 Counter 13 26
81878 0xA395 Units 0 65535 1 F60_6 units 6
81881 0xA398 Pre-set -2147483648 2147483647 1 F30 0 1
81883 0xA39A Compare -2147483648 2147483647 1 F30 0 1
81885 0xA39C Up 0 0xFFFFFFFF 1 FC142 0 1
81887 0xA39E Down 0 0xFFFFFFFF 1 FC142 0 1
81889 0xA3A0 Set to Pre-set 0 0xFFFFFFFF 1 FC142 0 1
81891 0xA3A2 Reset 0 0xFFFFFFFF 1 FC142 0 1
81893 0xA3A4 Freeze/Reset 0 0xFFFFFFFF 1 FC142 0 1
81895 0xA3A6 Freeze/Count 0 0xFFFFFFFF 1 FC142 0 1
81897 0xA3A8 Block 0 0xFFFFFFFF 1 FC142 0 1
81899 0xA3AA HI 13 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81901 0xA3AC EQL 13 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81903 0xA3AE LO 13 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81905 0xA3B0 Events 0 1 1 FC126 1 1
Digital Counter 14
81906 0xA3B1 Function 0 1 1 FC126 0 1
81907 0xA3B2 Name 0 65535 1 F60_26 Counter 14 26
81920 0xA3BF Units 0 65535 1 F60_6 units 6
81923 0xA3C2 Pre-set -2147483648 2147483647 1 F30 0 1
81925 0xA3C4 Compare -2147483648 2147483647 1 F30 0 1
81927 0xA3C6 Up 0 0xFFFFFFFF 1 FC142 0 1
81929 0xA3C8 Down 0 0xFFFFFFFF 1 FC142 0 1
81931 0xA3CA Set to Pre-set 0 0xFFFFFFFF 1 FC142 0 1
81933 0xA3CC Reset 0 0xFFFFFFFF 1 FC142 0 1
81935 0xA3CE Freeze/Reset 0 0xFFFFFFFF 1 FC142 0 1
81937 0xA3D0 Freeze/Count 0 0xFFFFFFFF 1 FC142 0 1
81939 0xA3D2 Block 0 0xFFFFFFFF 1 FC142 0 1
81941 0xA3D4 HI 14 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81943 0xA3D6 EQL 14 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81945 0xA3D8 LO 14 Output Relays 0 0xFFFFFFFF 1 FC198 0 1
81947 0xA3DA Events 0 1 1 FC126 1 1
Digital Counter 15
81948 0xA3DB Function 0 1 1 FC126 0 1
81949 0xA3DC Name 0 65535 1 F60_26 Counter 15 26
81962 0xA3E9 Units 0 65535 1 F60_6 units 6
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
