Technical specifications 5
Technical specifications
For UL compliant installation notes, refer to UL listed
installations on page 26
Operating temperature
range
-31 F (-35 C) to +150 F (+66 C)
Relative humidity 5% to 95% (non-condensing)
Physical dimensions
(HxWxD)
4.75" (121 mm) x 2.9" (74 mm) x 0.90" (23 mm)
Index of protection IP51
Input voltage range 10 to 15 VDC (measured at the reader)
Reader power
consumption
85 mA @ 12 VDC or 95 mA @ 15 VDC
Cable specifications Belden 8725 or equivalent, 20 AWG
minimum, shielded pairs
Maximum cabling
distance
a
a. The maximum cabling distance of 3,000 ft (914.4 meters) is influenced by a
number of factors including wire gauge and reader power requirements.
3000 ft (914 m) @ 12 VDC with 20 AWG cable
Read range ProxLite: up to 6 inches
ISO ProxLite: up to 5 inches
ProxLite Keytag: up to 3 inches
Operating modes Supervised F/2F
Unsupervised F/2F
b
Wiegand 40-bit
b
b. Operating the reader in this mode, requires a programming card for set up. Refer
to“Configuring the reader” on page 12 for more information.
Agency approvals FCC Class A
CE
