3/8” Self-tapping
Screws (12)
Installation
Bracket (2)
Window Lock
Bracket
Remote Control
Top Mounting Rail
(may be installed
already)
Foam Seal
3/8” Bracket
Screws (6)
1” Wood
Screws (8)
2-1/2” Flat Head Bolt and
Lock Nut (2)
ABC D
DELAY
MODE
ON/OFF
SPEED
TEMP/TIME
TEMP/TIME
Side Curtain
Frame
Left
Right
Side Curtain
(2)
Side Curtain
Foam (2)
Air
Conditioner
Bottom Seal and
Side Seals (6)
