GE AKD-10 - Application Data and Selection; WavePro Breaker Ratings; Breaker Configuration Guide

Table 12.3 shows the minimum and maximum fuse ratings allowed for WavePro breakers based on the breaker frame size
and rating plug. Maximum fuse ratings protect the circuit breaker under short circuit conditions with up to 200kA available.
Minimum fuse sizes are established based on UL continuous current tests when the fuse is mounted on the circuit breaker.
Table 12.3 Allowable current limiting fuse sizes for WavePro low voltage power circuit breakers (600Vac Max, 50/60 HZ)
*
These f
use sizes are also available as “Welder Limiters.”
À Class L fuses less than 800A are not UL or CSA listed. Use Class J fuses for 600A and below. The maximum fuse rating is the largest fuse that tests show will result in proper perfor-
mance of the breaker and fuse in combination under short-circuit conditions. Only Gould- Shawmut fuses should be used for proper coordination.
Á Fuses are mounted in a separate roll-out element (fuses shipped as “XS” material).
 Integrally fused 1600A frame breakers (WPF-16) equipped with 2500A fuses can be furnished with rating plugs from 300-1600A. Breakers equipped with 2500A fuses
cannot be modified to accept low
er rated f
uses. WPF-16 br
eakers equipped with 2000A and lower fuses cannot be upgraded to 2500A fuses. The maximum trip rating
for a WPF-16 br
eak
er is 1200A when f
urnished with other than 2500A f
uses (see char
t for min-max fuse rating for each rating plug value). 2500A fuses preclude the use of
shutters in the breaker cubicle.
Breaker Type Frame Size Sensor Rating Rating Plug Gould-Shawmut Fuse Range À
Below 150A
150A 150A 300 / 350 / 400 / 450 / 500 / 600 /
225A 800* / 1000* / 1200* / 1600*A
300A
WPF-08 800A 400A 400A 400 / 450 / 500 / 600 / 800* / 1000* / 1200* / 1600*A
600A 600 / 800* / 1000* / 1200* / 1600*A
700A
800* / 1000* / 1200* / 1600*
A
800A 800A 1000* / 1200* / 1600*A
400A and below
450 / 500 / 600 / 800* / 1000* / 1200* / 1600* / 2000* / 2500A
Â
500A 500 / 600 / 800* / 1000* / 1200* / 1600* / 2000* / 2500A Â
600A 600 / 800* / 1000* / 1200* / 1600* / 2000* / 2500A Â
700A
800* / 1000* / 1200* / 1600* / 2000* / 2500A
Â
WPF-16 Â 1600A
800A
800A
1000A 1000* / 1200* / 1600* / 2000* / 2500A Â
1200A 1600* / 2000* / 2500A Â
1600A
1600A
2500A
Â
WPS-20 Á 2000A 2000A 2000A and below 2000 / 2500A
WPS-32 Á 3200A
3200A 3200A and below 2000 / 2500 / 3000 / 4000A
WPS-40 Á 4000A 4000A 4000A and below
2000 / 2500 / 3000 / 4000 / 5000A
WPS-50 Á 5000A 5000A 5000A and below
12
Application data
Basic ratings
W
avePro
™
l
ow voltage power circuit breakers are available in
various levels of interrupting capacity (IC) and are identified
w
ith a suffix in the model number. WPS indicates “standard
IC,” WPH indicates “high IC,” WPX indicates “extended IC” and
WPF indicates “integrally fused.”
High IC and extended IC breakers are used with larger kVA
substation transformers as well as in parallelling applications.
Fused circuit breakers take the IC rating to 200kA rms
symmetrical for the highest short circuit applications.
Refer to Table 12.1 for the interrupting capacity (IC) of
WavePro breakers at system operating voltages.
WPS — Standard IC WPH — High IC
WPX — Extended IC WPF — Integrally fused (200kAIC)
Table 12.2 Breaker/Sensor/Rating Plug Combinations for Power+™,
and MicroVersaTrip Plus™/PM™
Table 12.1 WavePro Breaker Interrupting Ratings
Breaker Frame
Rating (Amps) Sensor Rating Available Rating Plugs
800 150 60
À
, 80, 100, 125, 150
800 400 150
À
, 200, 225, 250, 300, 400
800/1600 800 300
À
, 400, 450
À
, 500, 600, 700, 800
1600 1600 600
À
, 800, 1000, 1100
À
, 1200, 1600
2000 2000 750
À
, 800
À
, 1000, 1200, 1500
À
, 1600, 2000
3200 3200 1200, 1600, 2400, 3200
4000 4000 1600, 2000, 2500, 3000, 3600
À
, 4000
5000 Á 5000 Á 3200
À
, 4000
À
, 5000
À
À These rating plugs values are not available on Power+ trip units.
Á Power+ trip unit is not available on WPS-50 (5000A) breaker.
Short-Circuit Ratings
R
ated AC RMS Symmetrical kA
V
oltage, With Without
N
ominal Breaker Frame Short-Time Instantaneous Instantaneous
(max) Type Size (amps) Withstand Trip Trip
W
PS-08 800 30 30 30
WPH-08 800 42 42 42
WPX-08 800 50 50 50
600
W
PS-16 1600 42 42 42
WPH-16 1600 65 65 65
(635) WPS-20 2000 65 65 65
WPS-32 3200 65 65 65
WPH-32 3200 85 85 85
W
PX-32 3200 85 85 85
WPS-40 4000 85 85 85
WPX-40 4000 85 85 85
WPS-50 5000 85 85 85
WPX-50 5000 85 85 85
W
PS-08 800 30 30 30
WPH-08 800 42 42 42
WPX-08 800 65 65 65
480 WPS-16 1600 50 50 50
WPH-16 1600 65 65 65
(508) WPS-20 2000 65 65 65
WPS-32 3200 65 65 65
WPH-32 3200 85 85 85
WPX-32 3200 100 100 100
WPS-40 4000 85 85 85
WPX-40 4000 100 100 100
W
PS-50 5000 85 85 85
WPX-50 5000 100 100 100
WPS-08 800 30 42 30
WPH-08 800 42 50 42
WPX-08 800 65 65 65
240 WPS-16 1600 50 65 50
WPH-16 1600 65 65 65
(254) WPS-20 2000 65 65 65
WPS-32 3200 65 85 65
WPH-32 3200 85 130 85
WPX-32 3200 100 130 100
WPS-40 4000 85 130 85
WPX-40 4000 100 130 100
WPS-50 5000 85 130 85
WPX-50 5000 100 130 100
