54
F1XBBXQX
8 9 10 11 12 13 14 15
Hidden
“A - Disc” Close PB Operation Remote Charge
(See Note 3 Below) (E/O only) Counter Indicator Code
No
No
No
No X
No No No Yes (N.O.) A
No No Yes No B
No
No
Y
es
Y
es (N.O.) C
No
Yes No No D
No Yes No Yes (N.O.) E
No
Y
es
Y
es
No F
No
Yes Yes Yes (N.O.) G
Yes No No No H
Y
es
No
No
Y
es (N.O.) J
Y
es No Yes No K
Yes No Yes Yes (N.O.) L
No
No
No
Y
es (N.
C.) R
No No Yes Yes (N.C.) S
No
Y
es
No
Y
es (N.
C.)
T
No
Y
es
Y
es Yes (N.C.) V
Yes No No Yes (N.C.) W
Y
es
No
Y
es
Y
es (N.
C.)
Y
Note 3: ”A-Disconnect” (A-Disc) — the 36 point A-Disc is automatically
supplied whenever any of the following accessories/features are ordered:
zone selectiv
e int
erlock
, shunt trip
, auxiliar
y swit
ch, bell alarm, under
-
v
oltage, electric lock
out
, E/O
, MV
T PM.
Select the A-Disc if 4-wir
e GF is
r
equir
ed or if a br
eak
er is to be "PM R
eady"
and none of the abov
e
accessories/features ar
e or
dered.
"PM R
eady" wiring includes inputs for
24vDC auxiliar
y pow
er
, communications, and 3 phase v
oltage.
Operation
Charge & Close Code
manual X
manual with remote
close
¬
Close voltage
120v-60Hz 1
240v-60Hz 3
120v-50Hz 4
240v-50Hz 6
48v -DC A
110v-DC B
125v-DC C
250v-DC D
electrical
¬
Charge / Close
48v-DC E
120v-60Hz F
120v-50Hz H
120v-50
/
60/48v-DC N
110v-DC P
125v-DC Q
250v-DC R
240v-60Hz T
240v-50Hz W
¬ (
Requires min 4 stage auxil-
iary switch and shunt trip)
Shunt Trip-1
Code
none X
120VAC, 60Hz
¬
1
208VAC, 60Hz 2
240VAC, 60Hz
¬
3
70VAC, 60Hz 4
120VAC, 50Hz 5
208VAC, 50Hz 6
240V
A
C, 50Hz
7
Code
24VDC
¬
B
48VDC D
110 / 125VDC
¬
E
250VDC
¬
F
¬
Coil ratings av
ailable
for Shunt Trip-1 or
Shunt Trip-2. All
other ratings apply
to Shunt Trip-1 only.
Undervoltage (UV) or Electric Lockout (ELO) (See Note 2 Below)
Code
UV
UV w/TD ELO
none
X
XX
120V-50/60Hz 1 4
208V-50/60Hz
3 (T
AKYUV
T-5)
240V-50/60Hz 2 3 (TAKYUVT-4) 5
24VDC A G
48VDC B H
110VDC C J
125VDC
C E (TAKYUVT-1) J
250VDC D F (TAKYUVT-2) K
Note 2: Or
der Static Time Delay Unit (TAKYUVT-1,2,4,5) separately
AccessoryCode
none X
Aux switch
4 stages A
Aux switch
7 stages B
Accessory Accessory Code
Bell Alarm Push Button Cover
no no X
yes no A
yes, with lockout no B
no CLOSE pb C
yes CLOSE pb D
yes, with lockout CLOSE pb E
no OPEN pb F
yes OPEN pb G
yes, with lockout OPEN pb H
no CLOSE & OPEN pb J
yes CLOSE & OPEN pb K
yes, with lockout CLOSE & OPEN pb L
Future use
Breaker Operation
& Control Voltages Breaker Mounted Accessories
(Requires 4 or 7 stage aux. switch)
Accessory Code
none X
Shunt Trip-2 n (See “Shunt Trip-1”
(Requires 7 stage aux. switch) codes—only those
marked
¬
are
available for 2nd
shunt trip)
