DescriptionNo.DescriptionNo.
HisTrap column3Tubing from injection valve1
UV cell41/16" male connector2
Other unions and connectors might be required for other columns.
Note:
Preparing the fraction collector
1
Fill the fraction collector rack with, for example, 18 mm tubes (minimum 40 pcs.).
2
Adjust the height of the delivery arm using the lock knob (1) so that the bottom of
the tube sensor (2) is about 5 mm below the top of the tubes. The tubes should always
be below the horizontal mark on the tube sensor.
3
If necessary, adjust the length of the tubing exposed according to the sequence
shown below (the hole in the delivery arm used in step 3 and 4 is only used for ad-
justing the tubing length).
ÄKTAprime plus Operating Instructions 28-9597-89 AB 37
4 Operation
4.3 Preparations before start
