GE Multilin B30 Bus Differential System 2-3
2 PRODUCT DESCRIPTION 2.1 INTRODUCTION
2
2.1.2 ORDERING
a) OVERVIEW
The B30 is available as a 19-inch rack horizontal mount or reduced-size (¾) vertical unit and consists of the following mod-
ules: power supply, CPU, CT/VT, contact input and output, transducer input and output, and inter-relay communications.
Each of these modules can be supplied in a number of configurations specified at the time of ordering. The information
required to completely specify the relay is provided in the following tables (see chapter 3 for full details of relay modules).
Order codes are subject to change without notice. See the GE Multilin ordering page at
http://www.gedigitalenergy.com/multilin/order.htm
for the latest options.
The order code structure is dependent on the mounting option (horizontal or vertical) and the type of CT/VT modules
(enhanced diagnostic CT/VT modules or HardFiber
TM
process bus modules). The order code options are described in the
following sub-sections.
b) ORDER CODES WITH ENHANCED CT/VT MODULES
The order codes for the horizontal mount units are shown below.
Contact outputs (up to 64) IEC 61850 communications (optional) Time synchronization over SNTP
Control pushbuttons Metering: current, voltage, frequency Transducer inputs and outputs
CyberSentry™ security Modbus communications User-definable displays
Digital counters (8) Modbus user map User-programmable fault reports
Digital elements (48) Non-volatile latches User-programmable LEDs
Direct inputs and outputs (32) Non-volatile selector switch User-programmable pushbuttons
Disconnect switches Oscillography User-programmable self-tests
DNP 3.0 or IEC 60870-5-104 protocol Selector switch Virtual inputs (64)
Ethernet Global Data protocol (optional) Setting groups (6) Virtual outputs (96)
Table 2–3: B30 ORDER CODES FOR HORIZONTAL UNITS
B30 - * ** - * * * - F ** - H ** - L ** - N ** - S ** - U ** - W/X ** Full Size Horizontal Mount
BASE UNIT B30 | | | | | | | | | | | | Base Unit
CPU T | | | | | | | | | | | RS485 with 3 100Base-FX Ethernet, multimode, SFP with LC
U | | | | | | | | | | | RS485 with 1 100Base-T Ethernet, SFP RJ-45 + 2 100Base-FX Ethernet, multimode, SFP with LC
V | | | | | | | | | | | RS485 with 3 100Base-T Ethernet, SFP with RJ-45
SOFTWARE 00 | | | | | | | | | | No software options
01 | | | | | | | | | | Ethernet Global Data (EGD) protocol
03 | | | | | | | | | | IEC 61850 protocol
04 | | | | | | | | | | IEC 61850 and Ethernet Global Data (EGD) protocols
A0 | | | | | | | | | | CyberSentry Lvl 1
A1 | | | | | | | | | | CyberSentry Lvl 1 and Ethernet Global Data
A3 | | | | | | | | | | CyberSentry Lvl 1 and IEC 61850
A4 | | | | | | | | | | CyberSentry Lvl 1, Ethernet Global Data, and IEC 61850
B0 | | | | | | | | | | IEEE 1588
B1 | | | | | | | | | | IEEE 1588 and Ethernet Global Data
B3 | | | | | | | | | | IEEE 1588 and IEC 61850
B4 | | | | | | | | | | IEEE 1588, Ethernet Global Data, and IEC 61850
D0 | | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1
D1 | | | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and Ethernet Global Data
D3 | | | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and IEC 61850
D4 | | | | | | | | | | IEEE 1588, CyberSentry Lvl 1, Ethernet Global Data, and IEC 61850
Table 2–2: OTHER DEVICE FUNCTIONS
FUNCTION FUNCTION FUNCTION
