11-10 B30 Bus Differential System GE Multilin

11.6 DISPOSAL 11 MAINTENANCE

11.6DISPOSAL 11.6.1 DISPOSAL

Other than the battery, there are no special requirements for disposal of the unit at the end its service life. For customers

located in the European Union, dispose of the battery as outlined earlier. To prevent non-intended use of the unit, remove

the modules as outlined earlier, dismantle the unit, and recycle the metal when possible.
