A-10 B30 Bus Differential System GE Multilin
A.1 PARAMETER LISTS APPENDIX A
A
A.1.2 FLEXINTEGER ITEMS
FlexInteger items are also viewable in a web browser. In the browser, enter the IP address of the UR, access the Device
Information Menu option, then the FlexInteger Parameter Listing option.
39176 FlexElement 5 Value --- FlexElement 5 actual value
39178 FlexElement 6 Value --- FlexElement 6 actual value
39180 FlexElement 7 Value --- FlexElement 7 actual value
39182 FlexElement 8 Value --- FlexElement 8 actual value
45584 GOOSE Analog In 1 --- IEC 61850 GOOSE analog input 1
45586 GOOSE Analog In 2 --- IEC 61850 GOOSE analog input 2
45588 GOOSE Analog In 3 --- IEC 61850 GOOSE analog input 3
45590 GOOSE Analog In 4 --- IEC 61850 GOOSE analog input 4
45592 GOOSE Analog In 5 --- IEC 61850 GOOSE analog input 5
45594 GOOSE Analog In 6 --- IEC 61850 GOOSE analog input 6
45596 GOOSE Analog In 7 --- IEC 61850 GOOSE analog input 7
45598 GOOSE Analog In 8 --- IEC 61850 GOOSE analog input 8
45600 GOOSE Analog In 9 --- IEC 61850 GOOSE analog input 9
45602 GOOSE Analog In 10 --- IEC 61850 GOOSE analog input 10
45604 GOOSE Analog In 11 --- IEC 61850 GOOSE analog input 11
45606 GOOSE Analog In 12 --- IEC 61850 GOOSE analog input 12
45608 GOOSE Analog In 13 --- IEC 61850 GOOSE analog input 13
45610 GOOSE Analog In 14 --- IEC 61850 GOOSE analog input 14
45612 GOOSE Analog In 15 --- IEC 61850 GOOSE analog input 15
45614 GOOSE Analog In 16 --- IEC 61850 GOOSE analog input 16
63616 Bus 1 M_Id A --- Bus M_Id A
63618 Bus 1 M_Id B --- Bus M_Id B
63620 Bus 1 M_Id C --- Bus M_Id C
63622 Bus 1 M_Ir A --- Bus M_Ir A
63624 Bus 1 M_Ir B --- Bus M_Ir B
63626 Bus 1 M_Ir C --- Bus M_Ir C
63628 Bus 1 d_Ir A --- Bus d_Ir A
63630 Bus 1 d_Ir B --- Bus d_Ir B
63632 Bus 1 d_Ir C --- Bus d_Ir C
Table A–2: FLEXINTEGER DATA ITEMS
ADDRESS FLEXINTEGER NAME UNITS DESCRIPTION
9968 GOOSE UInt Input 1 --- IEC61850 GOOSE UInteger input 1
9970 GOOSE UInt Input 2 --- IEC61850 GOOSE UInteger input 2
9972 GOOSE UInt Input 3 --- IEC61850 GOOSE UInteger input 3
9974 GOOSE UInt Input 4 --- IEC61850 GOOSE UInteger input 4
9976 GOOSE UInt Input 5 --- IEC61850 GOOSE UInteger input 5
9978 GOOSE UInt Input 6 --- IEC61850 GOOSE UInteger input 6
9980 GOOSE UInt Input 7 --- IEC61850 GOOSE UInteger input 7
9982 GOOSE UInt Input 8 --- IEC61850 GOOSE UInteger input 8
9984 GOOSE UInt Input 9 --- IEC61850 GOOSE UInteger input 9
9986 GOOSE UInt Input 10 --- IEC61850 GOOSE UInteger input 10
9988 GOOSE UInt Input 11 --- IEC61850 GOOSE UInteger input 11
9990 GOOSE UInt Input 12 --- IEC61850 GOOSE UInteger input 12
Table A–1: FLEXANALOG DATA ITEMS (Sheet 10 of 10)
ADDRESS FLEXANALOG NAME UNITS DESCRIPTION
