5-88 B30 Bus Differential System GE Multilin
5.2 PRODUCT SETUP 5 SETTINGS
5
The G.703 modules are fixed at 64 kbps. The DIRECT I/O DATA RATE setting is not applicable to these modules.
The
DIRECT I/O CHANNEL CROSSOVER setting applies to B30s with dual-channel communication cards and allows crossing
over messages from channel 1 to channel 2. This places all UR-series IEDs into one direct input and output network
regardless of the physical media of the two communication channels.
The following application examples illustrate the basic concepts for direct input and output configuration. See the Inputs
and Outputs section in this chapter for information on configuring FlexLogic operands (flags, bits) to be exchanged.
Table 5–11: DIRECT INPUT AND OUTPUT DATA RATES
MODULE CHANNEL SUPPORTED DATA RATES
74 Channel 1 64 kbps
Channel 2 64 kbps
7L Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
7M Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
7P Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
7T Channel 1 64 kbps, 128 kbps
7W Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
7V Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
2A Channel 1 64 kbps
2B Channel 1 64 kbps
Channel 2 64 kbps
2G Channel 1 128 kbps
2H Channel 1 128 kbps
2I Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
2J Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
76 Channel 1 64 kbps
77 Channel 1 64 kbps
Channel 2 64 kbps
75 Channel 1 64 kbps
Channel 2 64 kbps
7E Channel 1 64 kbps
Channel 2 64 kbps
7F Channel 1 64 kbps
Channel 2 64 kbps
7G Channel 1 64 kbps
Channel 2 64 kbps
7Q Channel 1 64 kbps
Channel 2 64 kbps
7R Channel 1 64 kbps
7S Channel 1 64 kbps
Channel 2 64 kbps
NOTE
