GE Multilin B30 Bus Differential System 5-185
5 SETTINGS 5.7 CONTROL ELEMENTS
5
5.7.7 MONITORING ELEMENTS
a) MAIN MENU
PATH: SETTINGS  CONTROL ELEMENTS  MONITORING ELEMENTS
MONITORING
ELEMENTS
BREAKER
FLASHOVER 1
See page 5–186.
MESSAGE
BREAKER
FLASHOVER 2
See page 5–186.
MESSAGE
CT TROUBLE ZONE 1
See page 5–191.
MESSAGE
THERMAL OVERLOAD
PROTECTION
See page 5–192.
