GE Multilin B30 Bus Differential System 6-15
6 ACTUAL VALUES 6.3 METERING
6
b) PHASE CURRENT
PATH: ACTUAL VALUES  METERING SOURCE SRC 1 PHASE CURRENT
The metered phase current values are displayed in this menu. The "SRC 1" text will be replaced by whatever name was
programmed by the user for the associated source (see SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).
c) GROUND CURRENT
PATH: ACTUAL VALUES  METERING SOURCE SRC 1  GROUND CURRENT
The metered ground current values are displayed in this menu. The "SRC 1" text will be replaced by whatever name was
programmed by the user for the associated source (see
SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).
PHASE CURRENT
SRC 1
SRC 1 RMS Ia: 0.000
b: 0.000 c: 0.000 A
MESSAGE
SRC 1 RMS Ia:
0.000 A
MESSAGE
SRC 1 RMS Ib:
0.000 A
MESSAGE
SRC 1 RMS Ic:
0.000 A
MESSAGE
SRC 1 RMS In:
0.000 A
MESSAGE
SRC 1 PHASOR Ia:
0.000 A 0.0°
MESSAGE
SRC 1 PHASOR Ib:
0.000 A 0.0°
MESSAGE
SRC 1 PHASOR Ic:
0.000 A 0.0°
MESSAGE
SRC 1 PHASOR In:
0.000 A 0.0°
MESSAGE
SRC 1 ZERO SEQ I0:
0.000 A 0.0°
MESSAGE
SRC 1 POS SEQ I1:
0.000 A 0.0°
MESSAGE
SRC 1 NEG SEQ I2:
0.000 A 0.0°
GROUND CURRENT
SRC 1
SRC 1 RMS Ig:
0.000 A
MESSAGE
SRC 1 PHASOR Ig:
0.000 A 0.0°
MESSAGE
SRC 1 PHASOR Igd:
0.000 A 0.0°
