2-10 B30 Bus Differential System GE Multilin
2.2 ORDER CODES 2 PRODUCT DESCRIPTION
2
The order codes for the reduced size vertical mount units are shown below.
Table 2–5: B30 ORDER CODES (REDUCED SIZE VERTICAL UNITS)
B30 - * ** - * * * - F ** - H ** - L ** - N ** - R ** Reduced Size Vertical Mount
BASE UNIT B30 | | | | | | | | | | Base Unit
CPU T | | | | | | | | | RS485 with 3 100Base-FX Ethernet, multimode, SFP with LC
U | | | | | | | | | RS485 with 1 100Base-T Ethernet, SFP RJ-45 + 2 100Base-FX Ethernet, multimode, SFP with LC
V | | | | | | | | | RS485 with 3 100Base-T Ethernet, SFP with RJ-45
SOFTWARE 00 | | | | | | | | No software options
01 | | | | | | | | Ethernet Global Data (EGD) protocol
03 | | | | | | | | IEC 61850 protocol
04 | | | | | | | | IEC 61850 and Ethernet Global Data (EGD) protocols
A0 | | | | | | | | CyberSentry Lvl 1
A1 | | | | | | | | CyberSentry Lvl 1 and Ethernet Global Data
A3 | | | | | | | | CyberSentry Lvl 1 and IEC 61850
A4 | | | | | | | | CyberSentry Lvl 1, Ethernet Global Data, and IEC 61850
B0 | | | | | | | | IEEE 1588
B1 | | | | | | | | IEEE 1588 and Ethernet Global Data
B3 | | | | | | | | IEEE 1588 and IEC 61850
B4 | | | | | | | | IEEE 1588, Ethernet Global Data, and IEC 61850
C0 | | | | | | | | Parallel Redundancy Protocol (PRP)
C1 | | | | | | | | PRP and Ethernet Global Data
C3 | | | | | | | | PRP and IEC 61850
C4 | | | | | | | | PRP, Ethernet Global Data, and IEC 61850
D0 | | | | | | | | IEEE 1588 and CyberSentry Lvl 1
D1 | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and Ethernet Global Data
D3 | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and IEC 61850
D4 | | | | | | | | IEEE 1588, CyberSentry Lvl 1, Ethernet Global Data, and IEC 61850
E0 | | | | | | | | IEEE 1588 and PRP
E1 | | | | | | | | IEEE 1588, PRP, and Ethernet Global Dada
E3 | | | | | | | | IEEE 1588, PRP, and IEC 61850
E4 | | | | | | | | IEEE 1588, PRP, Ethernet Global Data, and IEC 61850
F0 | | | | | | | | PRP and CyberSentry Lvl1
F1 | | | | | | | | PRP, CyberSentry Lvl1, and Ethernet Global Data
F3 | | | | | | | | PRP, CyberSentry Lvl 1, and IEC 61850
F4 | | | | | | | | PRP, CyberSentry Lvl 1, Ethernet Global Data, and IEC 61850
G0 | | | | | | | | IEEE 1588, PRP, and CyberSentry Lvl 1
G1 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, Ethernet Global Data
G3 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and IEC 61850
G4 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, Ethernet Global Data, and IEC 61850
J0 | | | | | | | | IEC 60870-5-103
J1 | | | | | | | | IEC 60870-5-103 + EGD
J3 | | | | | | | | IEC 60870-5-103 + IEC 61850
J4 | | | | | | | | IEC 60870-5-103 + EGD + IEC 61850
K0 | | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103
K1 | | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + EGD
K3 | | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + IEC 61850
K4 | | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + EGD + IEC 61850
L0 | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1
L1 | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + EGD
L3 | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + IEC 61850
L4 | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + EGD + IEC 61850
MOUNT/COATING V | | | | | | | Vertical (3/4 rack)
B | | | | | | | Vertical (3/4 rack) with harsh-environmental coating
FACEPLATE/ DISPLAY F | | | | | | English display
K | | | | | | Enhanced front panel with English display
M | | | | | | Enhanced front panel with French display
Q | | | | | | Enhanced front panel with Russian display
U | | | | | | Enhanced front panel with Chinese display
L | | | | | | Enhanced front panel with English display and user-programmable pushbuttons
N | | | | | | Enhanced front panel with French display and user-programmable pushbuttons
T | | | | | | Enhanced front panel with Russian display and user-programmable pushbuttons
V | | | | | | Enhanced front panel with Chinese display and user-programmable pushbuttons
W | | | | | | Enhanced front panel with Turkish display
Y | | | | | | Enhanced front panel with Turkish display and user-programmable pushbuttons
I | | | | | | Enhanced front panel with German display
J | | | | | | Enhanced front panel with German display and user-programmable pushbuttons
POWER SUPPLY H | | | | | 125 / 250 V AC/DC power supply
L | | | | | 24 to 48 V (DC only) power supply
ENHANCED DIAGNOSTICS CT/VT DSP
(requires all DSP to be enhanced diagnostic)
XX | XX | | None (slots L and S only)
8L | 8L | | Standard 4CT/4VT with enhanced diagnostics
8M | 8M | | Sensitive ground 4CT/4VT with enhanced diagnostics
8N | 8N | | Standard 8CT with enhanced diagnostics
8R | 8R | | Sensitive ground 8CT with enhanced diagnostics
CONTACT INPUTS/OUTPUTS XX XX XX | No Module
4A 4A 4A | 4 Solid-State (no monitoring) MOSFET outputs
4B 4B 4B | 4 Solid-State (voltage with optional current) MOSFET outputs
4C 4C 4C | 4 Solid-State (current with optional voltage) MOSFET outputs
4D 4D 4D | 16 contact inputs with Auto-Burnishing (maximum of three modules within a case)
4L 4L 4L | 14 Form-A (no monitoring) Latching outputs
67 67 67 | 8 Form-A (no monitoring) outputs
6A 6A 6A | 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 contact inputs
6B 6B 6B | 2 Form-A (voltage with optional current) and 4 Form-C outputs, 4 contact inputs
6C 6C 6C | 8 Form-C outputs
6D 6D 6D | 16 contact inputs
6E 6E 6E | 4 Form-C outputs, 8 contact inputs
6F 6F 6F | 8 Fast Form-C outputs
6G 6G 6G | 4 Form-A (voltage with optional current) outputs, 8 contact inputs
6H 6H 6H | 6 Form-A (voltage with optional current) outputs, 4 contact inputs
6K 6K 6K | 4 Form-C and 4 Fast Form-C outputs
6L 6L 6L | 2 Form-A (current with optional voltage) and 2 Form-C outputs, 8 contact inputs
6M 6M 6M | 2 Form-A (current with optional voltage) and 4 Form-C outputs, 4 contact inputs
6N 6N 6N | 4 Form-A (current with optional voltage) outputs, 8 contact inputs
6P 6P 6P | 6 Form-A (current with optional voltage) outputs, 4 contact inputs
6R 6R 6R | 2 Form-A (no monitoring) and 2 Form-C outputs, 8 contact inputs
6S 6S 6S | 2 Form-A (no monitoring) and 4 Form-C outputs, 4 contact inputs
6T 6T 6T | 4 Form-A (no monitoring) outputs, 8 contact inputs
6U 6U 6U | 6 Form-A (no monitoring) outputs, 4 contact inputs
6V 6V 6V | 2 Form-A outputs, 1 Form-C output, 1 Form-A latching output, 8 contact inputs
