8-12 B30 Bus Differential System GE Multilin

8.6 OUTPUT LOGIC AND EXAMPLES 8 THEORY OF OPERATION

Figure 8–11: INTERNAL FAULT EXAMPLE

836736A1.CDR

The bus differential

protection element

picks up

The element

operates in

10ms

The

directional

flag is set

All the fault currents

are seen in one

direction

The saturation

flag is not set - no

directional

decision required
