GE Multilin B30 Bus Differential System 2-15

2 PRODUCT DESCRIPTION 2.2 ORDER CODES

The replacement module order codes for the reduced-size vertical mount units are shown below.

| 8R | Sensitive Ground 8CT with enhanced diagnostics

INTER-RELAY COMMUNICATIONS | 2A | C37.94SM, 1300 nm single-mode, ELED, 1 channel single-mode

| 2B | C37.94SM, 1300 nm single-mode, ELED, 2 channel single-mode

| 2E | Bi-phase, single channel

| 2F | Bi-phase, dual channel

| 2G | IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 1 Channel

| 2H | IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 2 Channels

| 2I | Channel 1 - IEEE C37.94, multimode, 64/128 kbps; Channel 2 - 1300 nm, single-mode, Laser

| 2J | Channel 1 - IEEE C37.94, multimode, 64/128 kbps; Channel 2 - 1550 nm, single-mode, Laser

| 72 | 1550 nm, single-mode, Laser, 1 Channel

| 73 | 1550 nm, single-mode, Laser, 2 Channel

| 74 | Channel 1 - RS422; Channel 2 - 1550 nm, single-mode, Laser

| 75 | Channel 1 - G.703; Channel 2 - 1550 nm, single-mode Laser

| 76 | IEEE C37.94, 820 nm, multimode, LED, 1 Channel

| 77 | IEEE C37.94, 820 nm, multimode, LED, 2 Channels

| 7A | 820 nm, multimode, LED, 1 Channel

| 7B | 1300 nm, multimode, LED, 1 Channel

| 7C | 1300 nm, single-mode, ELED, 1 Channel

| 7D | 1300 nm, single-mode, Laser, 1 Channel

| 7E | Channel 1 - G.703; Channel 2 - 820 nm, multimode

| 7F | Channel 1 - G.703; Channel 2 - 1300 nm, multimode

| 7G | Channel 1 - G.703; Channel 2 - 1300 nm, single-mode ELED

| 7H | 820 nm, multimode, LED, 2 Channels

| 7I | 1300 nm, multimode, LED, 2 Channels

| 7J | 1300 nm, single-mode, ELED, 2 Channels

| 7K | 1300 nm, single-mode, Laser, 2 Channels

| 7L | Channel 1 - RS422; Channel 2 - 820 nm, multimode, LED

| 7M | Channel 1 - RS422; Channel 2 - 1300 nm, multimode, LED

| 7N | Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, ELED

| 7P | Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, Laser

| 7Q | Channel 1 - G.703; Channel 2 - 1300 nm, single-mode Laser

| 7R | G.703, 1 Channel

| 7S | G.703, 2 Channels

| 7T | RS422, 1 Channel

| 7W | RS422, 2 Channels

TRANSDUCER

INPUTS/OUTPUTS

| 5A | 4 DCmA inputs, 4 DCmA outputs (only one 5A module is allowed)

| 5C | 8 RTD inputs

| 5D | 4 RTD inputs, 4 DCmA outputs (only one 5D module is allowed)

| 5E | 4 DCmA inputs, 4 RTD inputs

| 5F | 8 DCmA inputs

Table 2–9: ORDER CODES FOR REPLACEMENT MODULES, VERTICAL UNITS

UR - ** - *

POWER SUPPLY | SH B | 125 / 300 V AC/DC

| SL V | 24 to 48 V (DC only)

CPU | T | RS485 with 3 100Base-FX Ethernet, multimode, SFP with LC

| U | RS485 with 1 100Base-T Ethernet, SFP RJ-45 + 2 100Base-FX Ethernet, multimode, SFP with LC

| V | RS485 with 3 100Base-T Ethernet, SFP with RJ-45

FACEPLATE/DISPLAY | 3F | Vertical faceplate with keypad and English display

| 3D | Vertical faceplate with keypad and French display

| 3R | Vertical faceplate with keypad and Russian display

| 3A | Vertical faceplate with keypad and Chinese display

| 3K | Enhanced front panel with English display

| 3M | Enhanced front panel with French display

| 3Q | Enhanced front panel with Russian display

| 3U | Enhanced front panel with Chinese display

| 3L | Enhanced front panel with English display and user-programmable pushbuttons

| 3N | Enhanced front panel with French display and user-programmable pushbuttons

| 3T | Enhanced front panel with Russian display and user-programmable pushbuttons

| 3V | Enhanced front panel with Chinese display and user-programmable pushbuttons

| 3I | Enhanced front panel with German display

| 3J | Enhanced front panel with German display and user-programmable pushbuttons

CONTACT INPUTS/OUTPUTS | 4A | 4 Solid-State (no monitoring) MOSFET outputs

| 4B | 4 Solid-State (voltage with optional current) MOSFET outputs

| 4C | 4 Solid-State (current with optional voltage) MOSFET outputs

| 4D | 16 contact inputs with Auto-Burnishing

| 4L | 14 Form-A (no monitoring) Latching outputs

| 67 | 8 Form-A (no monitoring) outputs

| 6A | 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 contact inputs

| 6B | 2 Form-A (voltage with optional current) and 4 Form-C outputs, 4 contact inputs

| 6C | 8 Form-C outputs

| 6D | 16 contact inputs

| 6E | 4 Form-C outputs, 8 contact inputs

| 6F | 8 Fast Form-C outputs

| 6G | 4 Form-A (voltage with optional current) outputs, 8 contact inputs

| 6H | 6 Form-A (voltage with optional current) outputs, 4 contact inputs

| 6K | 4 Form-C and 4 Fast Form-C outputs

| 6L | 2 Form-A (current with optional voltage) and 2 Form-C outputs, 8 contact inputs

| 6M | 2 Form-A (current with optional voltage) and 4 Form-C outputs, 4 contact inputs

| 6N | 4 Form-A (current with optional voltage) outputs, 8 contact inputs

| 6P | 6 Form-A (current with optional voltage) outputs, 4 contact inputs

| 6R | 2 Form-A (no monitoring) and 2 Form-C outputs, 8 contact inputs

| 6S | 2 Form-A (no monitoring) and 4 Form-C outputs, 4 contact inputs

| 6T | 4 Form-A (no monitoring) outputs, 8 contact inputs

| 6U | 6 Form-A (no monitoring) outputs, 4 contact inputs

| 6V | 2 Form-A outputs, 1 Form-C output, 2 Form-A (no monitoring) latching outputs, 8 contact inputs

CT/VT MODULES

(NOT AVAILABLE FOR THE C30)

| 8L | Standard 4CT/4VT with enhanced diagnostics

| 8N | Standard 8CT with enhanced diagnostics
