GE Multilin B30 Bus Differential System B-11
APPENDIX B B.4 MEMORY MAPPING
B
043C Virtual Input 61 State 0 to 1 --- 1 F108 0 (Off)
043D Virtual Input 62 State 0 to 1 --- 1 F108 0 (Off)
043E Virtual Input 63 State 0 to 1 --- 1 F108 0 (Off)
043F Virtual Input 64 State 0 to 1 --- 1 F108 0 (Off)
IEC103 Protocol Settings (Read/Write Setting)
0582 IEC103 Common ASDU Address 0 to 254 --- 1 F001 0
0583 IEC103 Sync Timeout 1 to 1440 min 1 F001 1
IEC 103 Binary Inputs (Read/Write Setting) (96 modules)
0584 IEC103 Binary Input 1 FUN 0 to 255 --- 1 F001 0
0585 IEC103 Binary Input 1 INF 0 to 255 --- 1 F001 0
0586 IEC103 Binary Input 1 Operand 0 to 4294967295 --- 1 F300 0
0588 ...Repeated for Binary Input 2
058C ...Repeated for Binary Input 3
0590 ...Repeated for Binary Input 4
0594 ...Repeated for Binary Input 5
0598 ...Repeated for Binary Input 6
059C ...Repeated for Binary Input 7
05A0 ...Repeated for Binary Input 8
05A4 ...Repeated for Binary Input 9
05A8 ...Repeated for Binary Input 10
05AC ...Repeated for Binary Input 11
05B0 ...Repeated for Binary Input 12
05B4 ...Repeated for Binary Input 13
05B8 ...Repeated for Binary Input 14
05BC ...Repeated for Binary Input 15
05C0 ...Repeated for Binary Input 16
05C4 ...Repeated for Binary Input 17
05C8 ...Repeated for Binary Input 18
05CC ...Repeated for Binary Input 19
05D0 ...Repeated for Binary Input 20
05D4 ...Repeated for Binary Input 21
05D8 ...Repeated for Binary Input 22
05DC ...Repeated for Binary Input 23
05E0 ...Repeated for Binary Input 24
05E4 ...Repeated for Binary Input 25
05E8 ...Repeated for Binary Input 26
05EC ...Repeated for Binary Input 27
05F0 ...Repeated for Binary Input 28
05F4 ...Repeated for Binary Input 29
05F8 ...Repeated for Binary Input 30
05FC ...Repeated for Binary Input 31
0600 ...Repeated for Binary Input 32
0604 ...Repeated for Binary Input 33
0608 ...Repeated for Binary Input 34
060C ...Repeated for Binary Input 35
0610 ...Repeated for Binary Input 36
0614 ...Repeated for Binary Input 37
0618 ...Repeated for Binary Input 38
061C ...Repeated for Binary Input 39
Table B–10: MODBUS MEMORY MAP (Sheet 3 of 64)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
