B-80 B30 Bus Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F190
ENUMERATION: SIMULATED KEYPRESS
F192
ENUMERATION: ETHERNET OPERATION MODE
0 = Half-Duplex, 1 = Full-Duplex
F194
ENUMERATION: DNP SCALE
0 = 0.01, 1 = 0.1, 2 = 1, 3 = 10, 4 = 100, 5 = 1000, 6 = 10000,
7 = 100000, 8 = 0.001
F200
TEXT40: 40-CHARACTER ASCII TEXT
20 registers, 16 Bits: 1st Char MSB, 2nd Char LSB
F202
TEXT20: 20-CHARACTER ASCII TEXT
10 registers, 16 Bits: 1st Char MSB, 2nd Char LSB
F203
TEXT16: 16-CHARACTER ASCII TEXT
F204
TEXT80: 80-CHARACTER ASCII TEXT
F205
TEXT12: 12-CHARACTER ASCII TEXT
F206
TEXT6: 6-CHARACTER ASCII TEXT
F207
TEXT4: 4-CHARACTER ASCII TEXT
F209
TEXT65: 65-CHARACTER ASCII TEXT
F211
ENUMERATION: SOURCE SELECTION
0 = None, 1 = SRC 1, 2 = SRC 2, 3 = SRC 3, 4 = SRC 4,
5 = SRC 5, 6 = SRC 6
F213
TEXT32: 32-CHARACTER ASCII TEXT
F220
ENUMERATION: PUSHBUTTON MESSAGE PRIORITY
F232
ENUMERATION: CONFIGURABLE GOOSE Tx
DATASET ITEMS
Bitmask Keypress Bitmask Keypress
0 No key ---
use between real keys
23 Reset
24 User 1
1 1 25 User 2
2 2 26 User 3
3 3 27 User-programmable key 1
4 4 28 User-programmable key 2
5 5 29 User-programmable key 3
6 6 30 User-programmable key 4
7 7 31 User-programmable key 5
8 8 32 User-programmable key 6
9 9 33 User-programmable key 7
10 0 34 User-programmable key 8
11 Decimal Point 35 User-programmable key 9
12 Plus/Minus 36 User-programmable key 10
13 Value Up 37 User-programmable key 11
14 Value Down 38 User-programmable key 12
15 Message Up 39 User 4 (control pushbutton)
16 Message Down 40 User 5 (control pushbutton)
17 Message Left 41 User 6 (control pushbutton)
18 Message Right 42 User 7 (control pushbutton)
19 Menu 43 User-programmable key 13
20 Help 44 User-programmable key 14
21 Escape 45 User-programmable key 15
22 Enter 46 User-programmable key 16
Value Priority
0 Disabled
1Normal
2 High Priority
Value IEC 61850 Tx dataset item
0None
1 GGIO1.ST.Ind1.q
2 GGIO1.ST.Ind1.stVal
3 GGIO1.ST.Ind2.q
4 GGIO1.ST.Ind2.stVal
↓↓
255 GGIO1.ST.Ind128.q
256 GGIO1.ST.Ind128.stVal
257 MMXU1.MX.TotW.mag.f
258 MMXU1.MX.TotVAr.mag.f
259 MMXU1.MX.TotVA.mag.f
260 MMXU1.MX.TotPF.mag.f
261 MMXU1.MX.Hz.mag.f
262 MMXU1.MX.PPV.phsAB.cVal.mag.f
263 MMXU1.MX.PPV.phsAB.cVal.ang.f
264 MMXU1.MX.PPV.phsBC.cVal.mag.f
265 MMXU1.MX.PPV.phsBC.cVal.ang.f
266 MMXU1.MX.PPV.phsCA.cVal.mag.f
