B-96 B30 Bus Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F616
ENUMERATION: IEC 61850 GOOSE DATASET ITEMS
818 XSWI15.ST.Pos.stVal
819 XSWI16.ST.Loc.stVal
820 XSWI16.ST.Pos.stVal
821 XSWI17.ST.Loc.stVal
822 XSWI17.ST.Pos.stVal
823 XSWI18.ST.Loc.stVal
824 XSWI18.ST.Pos.stVal
825 XSWI19.ST.Loc.stVal
826 XSWI19.ST.Pos.stVal
827 XSWI20.ST.Loc.stVal
828 XSWI20.ST.Pos.stVal
829 XSWI21.ST.Loc.stVal
830 XSWI21.ST.Pos.stVal
831 XSWI22.ST.Loc.stVal
832 XSWI22.ST.Pos.stVal
833 XSWI23.ST.Loc.stVal
834 XSWI23.ST.Pos.stVal
835 XSWI24.ST.Loc.stVal
836 XSWI24.ST.Pos.stVal
837 XCBR1.ST.Loc.stVal
838 XCBR1.ST.Pos.stVal
839 XCBR2.ST.Loc.stVal
840 XCBR2.ST.Pos.stVal
841 XCBR3.ST.Loc.stVal
842 XCBR3.ST.Pos.stVal
843 XCBR4.ST.Loc.stVal
844 XCBR4.ST.Pos.stVal
845 XCBR5.ST.Loc.stVal
846 XCBR5.ST.Pos.stVal
847 XCBR6.ST.Loc.stVal
848 XCBR6.ST.Pos.stVal
Enumeration GOOSE dataset items
0 None
1 GGIO1.ST.Ind1.q
2 GGIO1.ST.Ind1.stVal
3 GGIO1.ST.Ind2.q
4 GGIO1.ST.Ind2.stVal
5 GGIO1.ST.Ind3.q
6 GGIO1.ST.Ind3.stVal
7 GGIO1.ST.Ind4.q
8 GGIO1.ST.Ind4.stVal
9 GGIO1.ST.Ind5.q
10 GGIO1.ST.Ind5.stVal
11 GGIO1.ST.Ind6.q
12 GGIO1.ST.Ind6.stVal
13 GGIO1.ST.Ind7.q
14 GGIO1.ST.Ind7.stVal
15 GGIO1.ST.Ind8.q
16 GGIO1.ST.Ind8.stVal
Enumeration IEC 61850 report dataset items
17 GGIO1.ST.Ind9.q
18 GGIO1.ST.Ind9.stVal
19 GGIO1.ST.Ind10.q
20 GGIO1.ST.Ind10.stVal
21 GGIO1.ST.Ind11.q
22 GGIO1.ST.Ind11.stVal
23 GGIO1.ST.Ind12.q
24 GGIO1.ST.Ind12.stVal
25 GGIO1.ST.Ind13.q
26 GGIO1.ST.Ind13.stVal
27 GGIO1.ST.Ind14.q
28 GGIO1.ST.Ind14.stVal
29 GGIO1.ST.Ind15.q
30 GGIO1.ST.Ind15.stVal
31 GGIO1.ST.Ind16.q
32 GGIO1.ST.Ind16.stVal
33 GGIO1.ST.Ind17.q
34 GGIO1.ST.Ind17.stVal
35 GGIO1.ST.Ind18.q
36 GGIO1.ST.Ind18.stVal
37 GGIO1.ST.Ind19.q
38 GGIO1.ST.Ind19.stVal
39 GGIO1.ST.Ind20.q
40 GGIO1.ST.Ind20.stVal
41 GGIO1.ST.Ind21.q
42 GGIO1.ST.Ind21.stVal
43 GGIO1.ST.Ind22.q
44 GGIO1.ST.Ind22.stVal
45 GGIO1.ST.Ind23.q
46 GGIO1.ST.Ind23.stVal
47 GGIO1.ST.Ind24.q
48 GGIO1.ST.Ind24.stVal
49 GGIO1.ST.Ind25.q
50 GGIO1.ST.Ind25.stVal
51 GGIO1.ST.Ind26.q
52 GGIO1.ST.Ind26.stVal
53 GGIO1.ST.Ind27.q
54 GGIO1.ST.Ind27.stVal
55 GGIO1.ST.Ind28.q
56 GGIO1.ST.Ind28.stVal
57 GGIO1.ST.Ind29.q
58 GGIO1.ST.Ind29.stVal
59 GGIO1.ST.Ind30.q
60 GGIO1.ST.Ind30.stVal
61 GGIO1.ST.Ind31.q
62 GGIO1.ST.Ind31.stVal
63 GGIO1.ST.Ind32.q
64 GGIO1.ST.Ind32.stVal
65 GGIO1.ST.Ind33.q
66 GGIO1.ST.Ind33.stVal
67 GGIO1.ST.Ind34.q
68 GGIO1.ST.Ind34.stVal
69 GGIO1.ST.Ind35.q
Enumeration GOOSE dataset items
