3-22 B30 Bus Differential System GE Multilin

3.2 WIRING 3 HARDWARE

Vresistor = 2 mA * 14 Kohm = 28 V

Vresistor < contact input threshold (84 V) (EQ 3.5)

In conclusion, in this example, the contact input does NOT operate falsely with the Burden Resistor across its input AND

when a battery ground is present.
