GE Multilin B30 Bus Differential System 3-27

3 HARDWARE 3.2 WIRING

Figure 3–24: RTD CONNECTION

Three-wire shielded cable

RTD terminals

Maximum total lead resistance:

25 ohms for Platinum RTDs

Route cable in separate conduit from

current carrying conductors

RTD

859736A1.CDR

RTD terminals

RTD

For RTD

RTD

SURGE

~1 &

~8b

~1a

~1b

~2a

Hot

Return

Comp

~2c

~1c
