GE Multilin C60 Breaker Protection System 4-21
4 HUMAN INTERFACES 4.3 FACEPLATE INTERFACE
4
1. Use the knife to lift the pushbutton label and slide the tail of the label tool underneath, as shown below. Make sure the
bent tab is pointing away from the relay.
2. Slide the label tool under the user-programmable pushbutton label until the tabs snap out as shown below. This
attaches the label tool to the user-programmable pushbutton label.
3. Remove the tool and attached user-programmable pushbutton label as shown below.
