5-128 C60 Breaker Protection System GE Multilin
5.4 SYSTEM SETUP 5 SETTINGS
5
b) BASIC CONFIGURATION
PATH: SETTINGS  SYSTEM SETUP PHASOR MEASUREMENT BASIC CONFIGURATION PMU1(2)
 PMU 1 BASIC
 CONFIGURATION
PMU 1
FUNCTION: Disabled
Range: Enabled, Disabled
MESSAGE
PMU 1 IDCODE:
1
Range: 1 to 65534 in steps of 1
MESSAGE
PMU 1 STN:
GE-UR-PMU
Range: 32-character ASCII string truncated to 16
characters if mapped into C37.118 Default: GE-UR-PMU
MESSAGE
PMU 1 SIGNAL SOURCE:
SRC 1
Range: Available signal sources
MESSAGE
PMU 1 CLASS:
CLASS M
Range: None, CLASS M, CLASS P
MESSAGE
PMU 1 FORMAT:
Integer
Range: Integer, Floating-point
MESSAGE
PMU 1 STYLE:
Polar
Range: Polar, Rectangular
MESSAGE
PMU 1 RATE:
10/sec
Range:1/sec, 2/sec, 4/sec, 5/sec, 10/sec, 12/sec, 15/sec,
20/sec, 25/sec, 30/sec, 50/sec, 60/sec, 100/sec, 120/sec
MESSAGE
PMU 1 PHS-1:
Off
Range: Available synchrophasor values
↓
MESSAGE
PMU 1 PHS-14:
Off
Range: Available synchrophasor values
MESSAGE
PMU 1 PHS-1
NAME: GE-UR-PMU-PHS-1
Range: 16 -character ASCII string
↓
MESSAGE
PMU 1 PHS-14:
NAME: GE-UR-PMU-PHS-14
Range: 16 -character ASCII string
MESSAGE
PMU 1 A-CH-1:
Off
Range: Available FlexAnalog values
↓
MESSAGE
PMU 1 A-CH-16 (16):
Off
Range: Available FlexAnalog values
MESSAGE
PMU 1 A-CH-1:
NAME: AnalogChannel1
Range: 16 -character ASCII string
↓
MESSAGE
PMU 1 A-CH-16 (16):
NAME: AnalogChannel16
Range: 16 -character ASCII string
MESSAGE
PMU 1 D-CH-1:
Off
Range: Available FlexLogic operands
↓
MESSAGE
PMU 1 D-CH-16:
Off
Range: FlexLogic operand
