GE Multilin C60 Breaker Protection System 5-127
5 SETTINGS 5.4 SYSTEM SETUP
5
Modification of SYNC Word in CFG-2 for TR 90-5 Data Sets
In the CFG-2 file, all relevant information about the data being streamed is included. However, this file does not include the
fact that it describes a 90-5 dataset or the number of Application Service Data Units (datasets). In order to communicate
this information via the CFG-2 file for a given aggregator, when the aggregator is set to 90-5, the version number of the
CFG-2 file (found in bits 0-3 of the frame SYNC word, which should presently be set to 2) is set as follows:
The PMU settings are organized in logical groups as follows. For correct PMU operation, upgrade the firmware to the latest
v7.2x release; consult the v7.2x Release Notes for information.
ATH: SETTINGS  SYSTEM SETUP  PHASOR MEASUREMENT UNIT  PHASOR MEASUREMENT UNIT 1(2)
VALUE
(DECIMAL) # OF ASDUS
11 1
12 2
13 3
14 4
 PHASOR MEASUREMENT
 UNIT 1
 PMU 1 BASIC
 CONFIGURATION
See page 5-128.
MESSAGE
 PMU 1
 CALIBRATION
See page 5-132.
MESSAGE
 PMU 1
 TRIGGERING
See page 5-133.
MESSAGE
 PMU 1
 RECORDING
See page 5-141.
