GE C60 User Manual

B-16 C60 Breaker Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
16D4 ...Repeated for Field Transducer 7
16D6 ...Repeated for Field Transducer 8
Source Current (Read Only) (4 modules)
1800 Source 1 Phase A Current RMS 0 to 999999.999 A 0.001 F060 0
1802 Source 1 Phase B Current RMS 0 to 999999.999 A 0.001 F060 0
1804 Source 1 Phase C Current RMS 0 to 999999.999 A 0.001 F060 0
1806 Source 1 Neutral Current RMS 0 to 999999.999 A 0.001 F060 0
1808 Source 1 Phase A Current Magnitude 0 to 999999.999 A 0.001 F060 0
180A Source 1 Phase A Current Angle -359.9 to 0 degrees 0.1 F002 0
180B Source 1 Phase B Current Magnitude 0 to 999999.999 A 0.001 F060 0
180D Source 1 Phase B Current Angle -359.9 to 0 degrees 0.1 F002 0
180E Source 1 Phase C Current Magnitude 0 to 999999.999 A 0.001 F060 0
1810 Source 1 Phase C Current Angle -359.9 to 0 degrees 0.1 F002 0
1811 Source 1 Neutral Current Magnitude 0 to 999999.999 A 0.001 F060 0
1813 Source 1 Neutral Current Angle -359.9 to 0 degrees 0.1 F002 0
1814 Source 1 Ground Current RMS 0 to 999999.999 A 0.001 F060 0
1816 Source 1 Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
1818 Source 1 Ground Current Angle -359.9 to 0 degrees 0.1 F002 0
1819 Source 1 Zero Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
181B Source 1 Zero Sequence Current Angle -359.9 to 0 degrees 0.1 F002 0
181C Source 1 Positive Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
181E Source 1 Positive Sequence Current Angle -359.9 to 0 degrees 0.1 F002 0
181F Source 1 Negative Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
1821 Source 1 Negative Sequence Current Angle -359.9 to 0 degrees 0.1 F002 0
1822 Source 1 Differential Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
1824 Source 1 Differential Ground Current Angle -359.9 to 0 degrees 0.1 F002 0
1825 Reserved (27 items) --- --- --- F001 0
1840 ...Repeated for Source 2
1880 ...Repeated for Source 3
18C0 ...Repeated for Source 4
Source Voltage (Read Only) (4 modules)
1A00 Source 1 Phase AG Voltage RMS 0 to 999999.999 V 0.001 F060 0
1A02 Source 1 Phase BG Voltage RMS 0 to 999999.999 V 0.001 F060 0
1A04 Source 1 Phase CG Voltage RMS 0 to 999999.999 V 0.001 F060 0
1A06 Source 1 Phase AG Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A08 Source 1 Phase AG Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A09 Source 1 Phase BG Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A0B Source 1 Phase BG Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A0C Source 1 Phase CG Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A0E Source 1 Phase CG Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A0F Source 1 Phase AB or AC Voltage RMS 0 to 999999.999 V 0.001 F060 0
1A11 Source 1 Phase BC or BA Voltage RMS 0 to 999999.999 V 0.001 F060 0
1A13 Source 1 Phase CA or CB Voltage RMS 0 to 999999.999 V 0.001 F060 0
1A15 Source 1 Phase AB or AC Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A17 Source 1 Phase AB or AC Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A18 Source 1 Phase BC or BA Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A1A Source 1 Phase BC or BA Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A1B Source 1 Phase CA or CB Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A1D Source 1 Phase CA or CB Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A1E Source 1 Auxiliary Voltage RMS 0 to 999999.999 V 0.001 F060 0
1A20 Source 1 Auxiliary Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A22 Source 1 Auxiliary Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A23 Source 1 Zero Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A25 Source 1 Zero Sequence Voltage Angle -359.9 to 0 degrees 0.1 F002 0
Table B–10: MODBUS MEMORY MAP (Sheet 8 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
