GE Multilin C60 Breaker Protection System B-17
APPENDIX B B.4 MEMORY MAPPING
B
1A26 Source 1 Positive Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A28 Source 1 Positive Sequence Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A29 Source 1 Negative Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A2B Source 1 Negative Sequence Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A2C Reserved (20 items) --- --- --- F001 0
1A40 ...Repeated for Source 2
1A80 ...Repeated for Source 3
1AC0 ...Repeated for Source 4
Source Power (Read Only) (4 modules)
1C00 Source 1 Three Phase Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
1C02 Source 1 Phase A Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
1C04 Source 1 Phase B Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
1C06 Source 1 Phase C Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
1C08 Source 1 Three Phase Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
1C0A Source 1 Phase A Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
1C0C Source 1 Phase B Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
1C0E Source 1 Phase C Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
1C10 Source 1 Three Phase Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
1C12 Source 1 Phase A Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
1C14 Source 1 Phase B Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
1C16 Source 1 Phase C Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
1C18 Source 1 Three Phase Power Factor -0.999 to 1 --- 0.001 F013 0
1C19 Source 1 Phase A Power Factor -0.999 to 1 --- 0.001 F013 0
1C1A Source 1 Phase B Power Factor -0.999 to 1 --- 0.001 F013 0
1C1B Source 1 Phase C Power Factor -0.999 to 1 --- 0.001 F013 0
1C1C Reserved (4 items) --- --- --- F001 0
1C20 ...Repeated for Source 2
1C40 ...Repeated for Source 3
1C60 ...Repeated for Source 4
Source Energy Metering (Read Only Non-Volatile) (4 modules)
1D00 Source 1 Positive Watthour 0 to 1000000000000 Wh 0.001 F060 0
1D02 Source 1 Negative Watthour 0 to 1000000000000 Wh 0.001 F060 0
1D04 Source 1 Positive Varhour 0 to 1000000000000 varh 0.001 F060 0
1D06 Source 1 Negative Varhour 0 to 1000000000000 varh 0.001 F060 0
1D08 Reserved (8 items) --- --- --- F001 0
1D10 ...Repeated for Source 2
1D20 ...Repeated for Source 3
1D30 ...Repeated for Source 4
Energy Commands (Read/Write Command)
1D60 Energy Clear Command 0 to 1 --- 1 F126 0 (No)
Source Frequency (Read Only) (4 modules)
1D80 Frequency for Source 1 2 to 90 Hz 0.001 F003 0
1D82 Frequency for Source 2 2 to 90 Hz 0.001 F003 0
1D84 Frequency for Source 3 2 to 90 Hz 0.001 F003 0
1D86 Frequency for Source 4 2 to 90 Hz 0.001 F003 0
Table B–10: MODBUS MEMORY MAP (Sheet 9 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
