B-20 C60 Breaker Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
Synchrocheck Actual Values (Read Only) (4 modules)
2400 Synchrocheck 1 Delta Voltage -1000000000000 to
1000000000000
V1F060 0
2402 Synchrocheck 1 Delta Frequency 0 to 655.35 Hz 0.01 F001 0
2403 Synchrocheck 1 Delta Phase 0 to 180 (not 0 to 359.9) degrees 0.1 F001 0
2404 ...Repeated for Synchrocheck 2
2408 ...Repeated for Synchrocheck 3
240C ...Repeated for Synchrocheck 4
Autoreclose Status (Read Only)
2410 Autoreclose 1 Count 0 to 65535 --- 1 F001 0
Field Unit Raw Data Settings (Read/Write Setting)
2460 Field Raw Data Port 0 to 7 --- 1 F244 6 (H1a)
2461 Field Raw Data Freeze 0 to 1 --- 1 F102 0 (Disabled)
Remote Double-Point Status Inputs (Read/Write Setting Registers) (5 modules)
2540 Remote Double-point Status Input 1 Device 1 to 32 --- 1 F001 1
2541 Remote Double-point Status Input 1 Item 0 to 64 --- 1 F606 0 (None)
2542 Remote Double-point Status Input 1 Name 1 to 64 --- 1 F205 "RemDPS Ip 1"
2548 Remote Double-point Status Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
2549 ... Repeated for Remote Double-point Status Input 2
2552 ... Repeated for Remote Double-point Status Input 3
255B ... Repeated for Remote Double-point Status Input 4
2564 ... Repeated for Remote Double-point Status Input 5
Phasor Measurement Unit Actual Values (Read Only) (2 modules)
256D PMU 1 Phase A Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
256F PMU Unit 1 Phase A Voltage Angle -180 to 180 ° 0.01 F002 0
2570 PMU 1 Phase B Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
2572 PMU 1 Phase B Voltage Angle -180 to 180 ° 0.01 F002 0
2573 PMU 1 Phase C Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
2575 PMU 1 Phase C Voltage Angle -180 to 180 ° 0.01 F002 0
2576 PMU 1 Auxiliary Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
2578 PMU 1 Auxiliary Voltage Angle -180 to 180 ° 0.01 F002 0
2579 PMU 1 Positive Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
257B PMU 1 Positive Sequence Voltage Angle -180 to 180 ° 0.01 F002 0
257C PMU 1 Negative Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
257E PMU 1 Negative Sequence Voltage Angle -180 to 180 ° 0.01 F002 0
257F PMU 1 Zero Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
2581 PMU 1 Zero Sequence Voltage Angle -180 to 180 ° 0.01 F002 0
2582 PMU 1 Phase A Current Magnitude 0 to 999999.999 A 0.001 F060 0
2584 PMU 1 Phase A Current Angle -180 to 180 ° 0.01 F002 0
2585 PMU 1 Phase B Current Magnitude 0 to 999999.999 A 0.001 F060 0
2587 PMU 1 Phase B Current Angle -180 to 180 ° 0.01 F002 0
2588 PMU 1 Phase C Current Magnitude 0 to 999999.999 A 0.001 F060 0
258A PMU 1 Phase C Current Angle -180 to 180 ° 0.01 F002 0
258B PMU 1 Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
258D PMU 1 Ground Current Angle -180 to 180 ° 0.01 F002 0
258E PMU 1 Positive Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
2590 PMU 1 Positive Sequence Current Angle -180 to 180 ° 0.01 F002 0
2591 PMU 1 Negative Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
2593 PMU 1 Negative Sequence Current Angle -180 to 180 ° 0.01 F002 0
2594 PMU 1 Zero Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
2596 PMU 1 Zero Sequence Current Angle -180 to 180 ° 0.01 F002 0
2597 PMU 1 Frequency 2 to 90 Hz 0.001 F003 0
2599 PMU 1 df/dt -327.67 to 327.67 Hz/s 0.01 F002 0
259A PMU 1 Configuration Change Counter 0 to 65535 --- 1 F001 0
Table B–10: MODBUS MEMORY MAP (Sheet 12 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
