GE C60 User Manual

GE Multilin C60 Breaker Protection System B-21
APPENDIX B B.4 MEMORY MAPPING
B
259B Reserved (4 items) 0 to 1 --- 1 F001 0
259F ...Repeated for PMU 2
Phasor Measurement Unit Integer (Read Only) (2 modules)
2699 PMU 1 SOC Timestamp 0 to 4294967295 seconds 1 F003 0
269B PMU 1 FRAMESEC Timestamp 0 to 4294967295 seconds 1 F003 0
269D PMU 1 STAT Flags 0 to 4294967295 --- 1 F003 0
269F ...Repeated for PMU 2
Phasor Measurement Unit Aggregator Actual Values (Read Only) (2 modules)
26BD PMU 1 Aggregator PDU Size --- --- --- F001 0
26BE ...Repeated for PMU 2
IEC 61850 GGIO5 Configuration (Read/Write Setting Registers) (16 modules)
26D0 IEC 61850 GGIO5 uinteger Input 1 Operand --- --- --- F612 0
26D1 IEC 61850 GGIO5 uinteger Input 2 Operand --- --- --- F612 0
26D2 IEC 61850 GGIO5 uinteger Input 3 Operand --- --- --- F612 0
26D3 IEC 61850 GGIO5 uinteger Input 4 Operand --- --- --- F612 0
26D4 IEC 61850 GGIO5 uinteger Input 5 Operand --- --- --- F612 0
26D5 IEC 61850 GGIO5 uinteger Input 6 Operand --- --- --- F612 0
26D6 IEC 61850 GGIO5 uinteger Input 7 Operand --- --- --- F612 0
26D7 IEC 61850 GGIO5 uinteger Input 8 Operand --- --- --- F612 0
26D8 IEC 61850 GGIO5 uinteger Input 9 Operand --- --- --- F612 0
26D9 IEC 61850 GGIO5 uinteger Input 10 Operand --- --- --- F612 0
26DA IEC 61850 GGIO5 uinteger Input 11 Operand --- --- --- F612 0
26DB IEC 61850 GGIO5 uinteger Input 12 Operand --- --- --- F612 0
26DC IEC 61850 GGIO5 uinteger Input 13 Operand --- --- --- F612 0
26DD IEC 61850 GGIO5 uinteger Input 14 Operand --- --- --- F612 0
26DE IEC 61850 GGIO5 uinteger Input 15 Operand --- --- --- F612 0
26DF IEC 61850 GGIO5 uinteger Input 16 Operand --- --- --- F612 0
IEC 61850 Received Integers (Read Only Actual Values) (16 modules)
26F0 IEC 61850 Received uinteger 1 0 to 4294967295 --- 1 F003 0
26F2 IEC 61850 Received uinteger 2 0 to 4294967295 --- 1 F003 0
26F4 IEC 61850 Received uinteger 3 0 to 4294967295 --- 1 F003 0
26F6 IEC 61850 Received uinteger 4 0 to 4294967295 --- 1 F003 0
26F8 IEC 61850 Received uinteger 5 0 to 4294967295 --- 1 F003 0
26FA IEC 61850 Received uinteger 6 0 to 4294967295 --- 1 F003 0
26FC IEC 61850 Received uinteger 7 0 to 4294967295 --- 1 F003 0
26FE IEC 61850 Received uinteger 8 0 to 4294967295 --- 1 F003 0
2700 IEC 61850 Received uinteger 9 0 to 4294967295 --- 1 F003 0
2702 IEC 61850 Received uinteger 10 0 to 4294967295 --- 1 F003 0
2704 IEC 61850 Received uinteger 11 0 to 4294967295 --- 1 F003 0
2706 IEC 61850 Received uinteger 12 0 to 4294967295 --- 1 F003 0
2708 IEC 61850 Received uinteger 13 0 to 4294967295 --- 1 F003 0
270A IEC 61850 Received uinteger 14 0 to 4294967295 --- 1 F003 0
270C IEC 61850 Received uinteger 15 0 to 4294967295 --- 1 F003 0
270E IEC 61850 Received uinteger 16 0 to 4294967295 --- 1 F003 0
Expanded FlexStates (Read Only)
2B00 FlexStates, one per register (256 items) 0 to 1 --- 1 F108 0 (Off)
Expanded Contact Input/Output States (Read Only)
2D00 Contact Input States, one per register (96 items) 0 to 1 --- 1 F108 0 (Off)
2D80 Contact Output States, one per register (64 items) 0 to 1 --- 1 F108 0 (Off)
2E00 Virtual Output States, one per register (96 items) 0 to 1 --- 1 F108 0 (Off)
Expanded Remote Input/Output Status (Read Only)
2F00 Remote Device States, one per register (32 items) 0 to 1 --- 1 F155 0 (Offline)
2F80 Remote Input States, one per register (64 items) 0 to 1 --- 1 F108 0 (Off)
Table B–10: MODBUS MEMORY MAP (Sheet 13 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
