B-22 C60 Breaker Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
Oscillography Values (Read Only)
3000 Oscillography Number of Triggers 0 to 65535 --- 1 F001 0
3001 Oscillography Available Records 0 to 65535 --- 1 F001 0
3002 Oscillography Last Cleared Date 0 to 400000000 --- 1 F050 0
3004 Oscillography Number Of Cycles Per Record 0 to 65535 --- 1 F001 0
Oscillography Commands (Read/Write Command)
3005 Oscillography Force Trigger 0 to 1 --- 1 F126 0 (No)
3011 Oscillography Clear Data 0 to 1 --- 1 F126 0 (No)
Oscillography Analog Values (Read Only)
3012 Oscillography Number of Triggers 0 to 32767 --- 1 F001 0
Fault Report Indexing (Read Only Non-Volatile)
3020 Number of Fault Reports 0 to 65535 --- 1 F001 0
Fault Report Actual Values (Read Only Non-Volatile) (15 modules)
3030 Fault Report 1 Time 0 to 4294967295 --- 1 F050 0
3032 Fault Report 2 Time 0 to 4294967295 --- 1 F050 0
3034 Fault Report 3 Time 0 to 4294967295 --- 1 F050 0
3036 Fault Report 4 Time 0 to 4294967295 --- 1 F050 0
3038 Fault Report 5 Time 0 to 4294967295 --- 1 F050 0
303A Fault Report 6 Time 0 to 4294967295 --- 1 F050 0
303C Fault Report 7 Time 0 to 4294967295 --- 1 F050 0
303E Fault Report 8 Time 0 to 4294967295 --- 1 F050 0
3040 Fault Report 9 Time 0 to 4294967295 --- 1 F050 0
3042 Fault Report 10 Time 0 to 4294967295 --- 1 F050 0
3044 Fault Report 11 Time 0 to 4294967295 --- 1 F050 0
3046 Fault Report 12 Time 0 to 4294967295 --- 1 F050 0
3048 Fault Report 13 Time 0 to 4294967295 --- 1 F050 0
304A Fault Report 14 Time 0 to 4294967295 --- 1 F050 0
304C Fault Report 15 Time 0 to 4294967295 --- 1 F050 0
Modbus File Transfer (Read/Write)
3100 Name of file to read --- --- --- F204 (none)
Modbus File Transfer Values (Read Only)
3200 Character position of current block within file 0 to 4294967295 --- 1 F003 0
3202 Size of currently-available data block 0 to 65535 --- 1 F001 0
3203 Block of data from requested file (122 items) 0 to 65535 --- 1 F001 0
Security (Read/Write Setting)
3280 Administrator Alphanumeric Password Setting --- --- --- F202 (none)
Security (Read Only)
328A Administrator Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
328B Administrator Alphanumeric Password Entry --- --- --- F202 (none)
Security (Read/Write Setting)
3295 Supervisor Alphanumeric Password Setting --- --- --- F202 (none)
Security (Read Only)
329F Supervisor Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
32A0 Supervisor Alphanumeric Password Entry --- --- --- F202 (none)
Security (Read/Write Setting)
32AA Engineer Alphanumeric Password Setting --- --- --- F202 (none)
Security (Read Only)
32B4 Engineer Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
32B5 Engineer Alphanumeric Password Entry --- --- --- F202 (none)
Security (Read/Write Setting)
32BF Operator Alphanumeric Password Setting --- --- --- F202 (none)
Table B–10: MODBUS MEMORY MAP (Sheet 14 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
