GE Multilin C60 Breaker Protection System B-23
APPENDIX B B.4 MEMORY MAPPING
B
Security (Read Only)
32C9 Operator Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
32CA Operator Alphanumeric Password Entry --- --- --- F202 (none)
Security (Read/Write Setting)
32D4 Observer Alphanumeric Password Setting --- --- --- F202 (none)
Security (Read Only)
32DE Observer Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
32DF Observer Alphanumeric Password Entry --- --- 1 F202 (none)
Security (Read Only)
32E9 Reserved for password settings of future roles (63 items) 0 to 65535 --- 1 F001 0
3328 Security Status Indicator 0 to 65535 --- 1 F618 0
Security (Read/Write Setting)
3329 Session Lockout 0 to 99 --- 1 F001 3
332A Session Lockout Period 0 to 9999 min 1 F001 3
332B Load Factory Defaults 0 to 1 --- 1 F126 0 (No)
332C Syslog Server IP Address 0 to 4294967295 --- 1 F003 0
332E Syslog Server Port Number 1 to 65535 --- 1 F001 514
Security Supervisory (Read/Write Setting)
3331 Device Authentication Enable 0 to 1 --- 1 F126 1 (Yes)
3332 Supervisor Role Enable 0 to 1 --- 1 F102 0 (Disabled)
3333 Lock Relay 0 to 1 --- 1 F102 0 (Disabled)
3334 Factory Service Mode Enable 0 to 1 --- 1 F102 0 (Disabled)
3335 Failed Authentication Alarm Enable 0 to 1 --- 1 F102 1 (Enabled)
3336 Firmware Lock Alarm 0 to 1 --- 1 F102 1 (Enabled)
3337 Settings Lock Alarm 0 to 1 --- 1 F102 1 (Enabled)
3338 Bypass Access 0 to 3 --- 1 F628 0 (Disabled)
333A Serial Inactivity Timeout 1 to 9999 --- 1 F001 1
Security Command (Read/Write Command)
3350 Operator Logoff 0 to 1 --- 1 F126 0 (No)
3351 Engineer Logoff 0 to 1 --- 1 F126 0 (No)
3352 Administrator Logoff 0 to 1 --- 1 F126 0 (No)
3353 Clear Security Data 0 to 1 --- 1 F126 0 (No)
Security Reserved Modbus Registers (Read/Write)
3360 Address 0x3360 reserved for serial login (20 items) 0 to 9999 --- 1 F001 3
3374 Address 0x3374 reserved for serial logout 0 to 9999 --- 1 F001 3
Security Reserved Modbus Registers (Read Only)
3375 Address 0x3374 reserved for serial logout 0 to 5 --- 1 F617 3 (Engineer)
Event Recorder (Read Only)
3400 Events Since Last Clear 0 to 4294967295 --- 1 F003 0
3402 Number of Available Events 0 to 4294967295 --- 1 F003 0
3404 Event Recorder Last Cleared Date 0 to 4294967295 --- 1 F050 0
Event Recorder Commands (Read/Write Command)
3406 Event Recorder Clear Command 0 to 1 --- 1 F126 0 (No)
DCmA Input Values (Read Only) (24 modules)
34C0 DCmA Inputs 1 Value -9999.999 to 9999.999 --- 0.001 F004 0
34C2 DCmA Inputs 2 Value -9999.999 to 9999.999 --- 0.001 F004 0
34C4 DCmA Inputs 3 Value -9999.999 to 9999.999 --- 0.001 F004 0
34C6 DCmA Inputs 4 Value -9999.999 to 9999.999 --- 0.001 F004 0
34C8 DCmA Inputs 5 Value -9999.999 to 9999.999 --- 0.001 F004 0
34CA DCmA Inputs 6 Value -9999.999 to 9999.999 --- 0.001 F004 0
34CC DCmA Inputs 7 Value -9999.999 to 9999.999 --- 0.001 F004 0
34CE DCmA Inputs 8 Value -9999.999 to 9999.999 --- 0.001 F004 0
Table B–10: MODBUS MEMORY MAP (Sheet 15 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
