GE C60 User Manual

GE Multilin C60 Breaker Protection System B-41
APPENDIX B B.4 MEMORY MAPPING
B
Sensitive Directional Power (Read/Write Grouped Setting) (2 modules)
6680 Sensitive Directional Power 1 Function 0 to 1 --- 1 F102 0 (Disabled)
6681 Sensitive Directional Power 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
6682 Sensitive Directional Power 1 RCA 0 to 359 degrees 1 F001 0
6683 Sensitive Directional Power 1 Calibration 0 to 0.95 degrees 0.05 F001 0
6684 Sensitive Directional Power 1 STG1 SMIN -1.2 to 1.2 pu 0.001 F002 100
6685 Sensitive Directional Power 1 STG1 Delay 0 to 600 s 0.01 F001 50
6686 Sensitive Directional Power 1 STG2 SMIN -1.2 to 1.2 pu 0.001 F002 100
6687 Sensitive Directional Power 1 STG2 Delay 0 to 600 s 0.01 F001 2000
6688 Sensitive Directional Power 1 Block 0 to 4294967295 --- 1 F300 0
668A Sensitive Directional Power 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
668B Sensitive Directional Power 1 Events 0 to 1 --- 1 F102 0 (Disabled)
668C Reserved (5 items) 0 to 65535 --- 1 F001 0
6691 ...Repeated for Sensitive Directional Power 2
Autoreclose 1P 3P (Read/Write Setting)
6860 Autoreclose Mode 0 to 3 --- 1 F622 0 (Mode 1 (1 & 3
Pole))
6861 Autoreclose Maximum Number of Shots 1 to 4 --- 1 F001 2
6862 Autoreclose Block Breaker 1 0 to 4294967295 --- 1 F300 0
6864 Autoreclose Close Time Breaker 1 0 to 655.35 s 0.01 F001 10
6865 Autoreclose Breaker Manual Close 0 to 4294967295 --- 1 F300 0
6867 Autoreclose Function 0 to 1 --- 1 F102 0 (Disabled)
6868 Autoreclose Block Time Manual Close 0 to 655.35 s 0.01 F001 1000
6869 Autoreclose 1P Initiate 0 to 4294967295 --- 1 F300 0
686B Autoreclose 3P Initiate 0 to 4294967295 --- 1 F300 0
686D Autoreclose 3P TD Initiate 0 to 4294967295 --- 1 F300 0
686F Autoreclose Multi-Phase Fault 0 to 4294967295 --- 1 F300 0
6871 Autoreclose Breaker 1 Pole Open 0 to 4294967295 --- 1 F300 0
6873 Autoreclose Breaker 3 Pole Open 0 to 4294967295 --- 1 F300 0
6875 Autoreclose 3-Pole Dead Time 1 0 to 655.35 s 0.01 F001 50
6876 Autoreclose 3-Pole Dead Time 2 0 to 655.35 s 0.01 F001 120
6877 Autoreclose Extend Dead T1 0 to 4294967295 --- 1 F300 0
6879 Autoreclose Dead T1 Extension 0 to 655.35 s 0.01 F001 50
687A Autoreclose Reset 0 to 4294967295 --- 1 F300 0
687C Autoreclose Reset Time 0 to 655.35 s 0.01 F001 6000
687D Autoreclose Breaker Closed 0 to 4294967295 --- 1 F300 0
687F Autoreclose Block 0 to 4294967295 --- 1 F300 0
6881 Autoreclose Pause 0 to 4294967295 --- 1 F300 0
6883 Autoreclose Incomplete Sequence Time 0 to 655.35 s 0.01 F001 500
6884 Autoreclose Block Breaker 2 0 to 4294967295 --- 1 F300 0
6886 Autoreclose Close Time Breaker 2 0 to 655.35 s 0.01 F001 10
6887 Autoreclose Transfer 1 to 2 0 to 1 --- 1 F126 0 (No)
6888 Autoreclose Transfer 2 to 1 0 to 1 --- 1 F126 0 (No)
6889 Autoreclose Breaker 1 Fail Option 0 to 1 --- 1 F081 0 (Continue)
688A Autoreclose Breaker 2 Fail Option 0 to 1 --- 1 F081 0 (Continue)
688B Autoreclose 1P Dead Time 0 to 655.35 s 0.01 F001 100
688C Autoreclose Breaker Sequence 0 to 4 --- 1 F082 3 (1 - 2)
688D Autoreclose Transfer Time 0 to 655.35 s 0.01 F001 400
688E Autoreclose Event 0 to 1 --- 1 F102 0 (Disabled)
688F Autoreclose 3P Dead Time 3 0 to 655.35 s 0.01 F001 200
6890 Autoreclose 3P Dead Time 4 0 to 655.35 s 0.01 F001 400
6891 Autoreclose Bus Fault Initiate 0 to 4294967295 --- 1 F300 0
6893 Autoreclose Initiate Mode 0 to 1 --- 1 F610 0 (Protection AND
CB)
Table B–10: MODBUS MEMORY MAP (Sheet 33 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
